62.5/125um Multimode Simplex Tight Buffer Round Riser Indoor Fiber Optic Cable
- Shenzhen
- T/T L/C D/P D/A Credit Card
You May Like
-
50/125um Multimode OM2 Simplex Tight Buffer Round Indoor Fiber Optic Cable
-
Fiber Optic Panel, Fiber Optic Enclosures, Optical Cable
-
10G OM4 50/125um Multimode Simplex Tight Buffer Round Riser Indoor Fiber Optic Cable
-
Indoor OM3 4 Fiber Optic Cable Price for Cape Verde Cabling Systems
-
Multi Mode 50/125 OM3 Indoor 8 Core Internal/ External Distribution Cable
-
Indoor Multi Purpose Distribution Cable
Product Details
| Place of Origin | Guangdong, China | Brand Name | NECERO | |
| Model Number | GJFJV | Type | Coaxial | |
| Number of Conductors | 1 |
Product Description
GJFJV/GJFJH fibre optic wires
Fiber color code
| No | 1 |
| Color | White |
Technical Parameters
| Cable type | Fiber count | Cable diameter | Cable weight | Tensile Strength | Crush resistance | Bending Radius |
| mm | kg/km | Long/short Term N | Long/Short Term N/100mm | Static/Dynamic mm | ||
| GJFJV/GJFJH | 1 | 2.0mm | 5 | 60/120 | 100/1000 | 10D/20D |
| GJFJV/GJFJH | 1 | 3.0mm | 9 | 80/150 | 500/1000 | 10D/20D |
Storage/Operating Temperature : -40℃ to + 70℃
Product Attenuation
| 2-96 fibers | 98-288fibers | ||
Max. Tension (N) | Short-term | 1500 | 3000 | |
Max. Tension (N) | Long-term | 600 | 1000 | |
Max. Crushing Resistance (N/100mm2) | 1000 | |||
Temperature range(°C) | -40°C-- +70°C | |||
Min. Bending Radius(mm) | Install | 20D | ||
Min. Bending Radius(mm) | Static | 10D | ||
Optical Characteristics
G.652 | G.655 | 50/125μm | 62.5/125μm | ||
Attenuation (+20°C) | @850nm |
|
| ≤3.0 dB/km | ≤3.0 dB/km |
@1300nm |
|
| ≤1.0 dB/km | ≤1.0 dB/km | |
@1310nm | ≤0.36 dB/km | ≤0.40 dB/km |
|
| |
@1550nm | ≤0.22 dB/km | ≤0.23dB/km |
|
| |
Bandwidth (Class A) | @850nm |
|
| ≥500 MHz·km | ≥200 MHz·km |
@1300nm |
|
| ≥1000 MHz·km | ≥600 MHz·km | |
Numerical Aperture |
|
| 0.200±0.015NA | 0.275±0.015NA | |
Cable Cut-off Wavelength λcc | ≤1260nm | ≤1480nm |
|
| |
Fiber pigtails are a great solution for fusion splicing inside of a fiber optic enclosure. The fan-out fiber pigtails come with a partial outer jacket to help protect the tight buffer fibers from being damaged. If space is a premium, the outer jacket can easily be removed, allowing the pigtails to have a tighter bend radius and take up less space.
Features
-Low insertion loss, Low back reflection loss
-Flexible and easy to strip fibre buffering
-Identifiable fibre buffer colours under all lighting conditions
-Reduces installation time
-Avoids incorrect patching by possible fiber flipping
Installation
Indoor Distribution
FAQ
1. Are you the real factory?
Yes,we are the real factory with 15 years’ history.
2. What is your fiber brand?
Fiber brands including : Corning, Fujikura,YOFC,FiberHome
3. What is your main products?
Outdoor fiber optic cables; indoor fiber optic cables;FTTH Drop cables; ADSS;
Indoor armored patch cords fiber cable; Optical patch cords SC/LC/FC/ST; MTP/MPO optical patch cord.
4. Product quality guarantee period?
25 years’ Guarantee for fiber optic cable
5. Do you have certificate for raw material?
We build long-term relationship cooperation with qualified ISO9001, ROHS raw material suppliers.
6. What is your delivery time?
Within 24 hours for 30KM normal kinds of fiber optic cable;
1 ~2 days for fiber optic patch cords with 10000 connectors.
7. MOQ: what is your minimum quantity?
MOQ for fiber optic cables: 1KM
There is no MOQ required for fiber optic patch cords,as there’s stock for normal kinds.
8. Do you have distributor in other country or domestic?
Until now, we sell our products to customers directly. And factory price could be offered.
9. Payment
For large orders: T/T, L/C
For small orders: T/T,Western Union and Paypal are acceptable.
10. Shipping & Delivery
For large orders: by sea (LCL or FCL)
For small orders: by sea (LCL), by air or by courier services,any of which is optional.
