Tilt Sensor Module Tilt Switch Angle Moudle Ball Switch Dumping Sensor
USD $0.76 - $0.89
/ Piece
1 Piece(Min.Order)
- SHENZHEN/HK
- Credit Card
You May Like
-
GY-30 BH1750 BH1750FVI Chip Light Intensity Sensor Light Illumination Module
-
ADXL345 Digital Acceleration Module Tilt Sensor Moudle
-
High Precision Si7021 Temperature and Humidity Sensor Module I2C Interface
-
Car Helicopter Crash Collision Sensor Impact Switch Module Robot Model For Arduino with Dupont Cable
-
Similar NRF24L01 + 2.4G Wireless Data Transmission Module 1.27 SMD
-
CSR8645 4.0 Low Power Consumption Bluetooth Stereo Audio Module Supports APTx
Product Details
| Place of Origin | Guangdong, China | Brand Name | Tilt Sensor Module | |
| Model Number | Tilt Sensor Module |
Product Description
Note
Please kindly be noted that the color of dupont cable may be different from the picture. Thank you!
Module Features
1. Sensor can sense changes in the angle of the object
2. working voltage 3.3V-5V
3. output format: Digital switching output (0 and 1)
4. with bolt holes for easy installation
5. small plate PCB size: 3cm x 1.6cm
6. using a wide voltage LM393 comparator
Module Interface Description ( 3 -wire)
1. VCC external 3.3V-5V voltage (can be directly connected to 3.3v & 5v microcontroller)
2. GND GND External
3. DO small board digital output interfaces ( 0 and 1 )
4. Note : AO is not valid here.
Module for use
1. the module wiring Consider the following wiring diagram, a detailed description;
2. the module output switch conduction angle-dependent switch and disconnect switch is turned off when the angle, DO output high, angle switch is turned on, DO output low;
3. the output can be directly connected with the microcontroller through the microcontroller to detect high and low, thereby detecting angle is changed;
4. the output can directly drive the relay module, which can be composed of a high-power angle switching, protection of electrical equipment and other products dumped automatically when power function.
