Line Marking Machine
- Qingdao/Tianjin
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Henan, China | Brand Name | DY | |
| Model Number | DY-HPT |
Product Description
Specifications
Thermoplastic Line Marking Machine1.Marking width:100~300mm
2.Thickness:1.5-2.5mm
Line Marking Machine
Description of Thermoplastic Line Marking Machine
DY-HPT Hand-Push Thermoplastic Line Marking Machine Marking Width is 100,150,200,300mm, and thickness is 1.5-2.5mm through adjusting the screeding knife.
Main Feature of DY-HPT Line Marking Machine
1. Ideal machine for medium-sized and small marking jobs in urban areas and road.
2. The screeding structure makes the markings straight and beautiful.
3. Easily operative to ensure the marking speed and quanlity.
4. Dual-use machine,also can change marking shoe for zebra crossing marking.
Technical Parameter of DY-HPT Thermoplastic Line Marking Machine
No. | Item | Spec. |
1 | Paint Tank | 55L (Erect type stirring device, Heating and keeping the temperature automatically) |
2 | Marking Mode | Screeding with marking shoe |
3 | Marking Shoe=Line Width | 100/150/200/300/400/450mm (Optional) |
4 | Glass Beads Bin | 12L (Bin with window, which can check the quantity of glass beads) |
5 | Glass Beads Dispenser | Automatic quantitative dispenser synchronous with the paint screeding system |
6 | Standard Configuration | 150mm Marking shoe (High temperature, oxidation and deformation resistance) |
7 | Rear Wheel Directional Device | Ensure the machine moving in straight line or turning freely in curved road |
8 | Guide Rod | Hydraulic guide rod |
9 | Size and Weight | 1210*890*970mm 165kg |
