Vacuum Tube Solar Collector Supplier In China (50Tube)

FOB Price

US$ 60 - 280 / Set

1 Set(Min. Order)

Port Shanghai Ningbo Sea-[prt
Payment TermsT/T L/C D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Type	Evacuated Tube	Pressure	Unpressurized
Circulation Type	Direct / Open Loop (Active)	Heating System	Thermosyphon (Passive)
Connection Type	Direct-Plug	Installation	Freestanding
Housing Material	Other, Galvanized Steel	Certification	CE, Other, CE, ISO9001:2000
Place of Origin	Zhejiang, China	Brand Name	Vacuum Tube Solar Collector,OEM,FADI
Model Number	FD-NPC58-50F

Product Description

Vacuum tube solar collector details:
Model: FD-NPC58-50F

Vacuum tube solar collector features

1. Temperature conservation layer in chest
2. Economical and practical
3. Environmental conservation and energy saving
4. According to the required configuration, it can be divided into two types, one is vertical and the other is horizontal

Vacuum tube solar collector applications
1. Hotels, resorts, hospitals and hostels
2. Process industry, boiler feed, laundry and canteens
3. Agricultural sector, hatcheries and dairies
4. Process industry, Boiler feed, Laundry and canteens
5. Agricultural sector, hatcheries, and dairies
6. Swimming pool heating
7. In-process heating
8. Health clubs (Steam / Sauna)

Seperated swimming pool solar collector material specification

Descripition	Vacuum tube solar collector
Material of out manifold	0.31-0.4mm thickness color steel/ fluorine carbon steel
Material of inner tank	Food grade 0.4mm thickness SUS304 stainless steel
Tank insulating layer	40mm 45kg/m³ high-density polyurethane foamed
Inlet and outlet hole	Male G3/4
Max pressure	0.05 Mpa
Solar collector tube	3.3 Borosilicate glass with N/Al coating
Thickness of glass tube	1.6mm
Vacuum tube tightness	P≤0.005 Pa
Absorption	as=0.93-0.96(AM1.5)
Emission ratio	εh=0.04-0.06(80C±5C)
Idle sunning property parameters	Y=220~260m2.C/KW
Average heat loss coefficient	ULT=0.6~0.7W/(m2.C)
Bracket:	1.5mm thickness Galvanized Steel
Welding:	Argon arc welding
Fastening pieces:	Made of stainless steel screw
Absorber area	4.686 m²
Tube quantity	50 tube 58x1,800mm
