2500W DC to AC Inverter With Charger (FD-IC-2500P)
- Shanghai /Ningbo
- T/T Credit Card
You May Like
-
30KW DC to AC Power Inverter (FD-GW-30000TL3)
-
3KW DC to AC Inverter 3000w (FD-GW-3000S)
-
3KW DC to AC Solar Power Inverter (FD-3000-NS)
-
500W DC to AC Smart Grid Tie Inverter (FD-GT-500W)
-
20KW DC to AC Solar On Grid Inverter /Grid Tie Inverter (FD-20K-DT)
-
5KW DC to AC Grid Tie Solar Inverter /Solar System Inverter (FD-5000D-NS)
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Inverter With Charger ,OEM,FADI | |
| Model Number | FD-IC-2500P | Specification | Normal | |
| Application | Commercial | Output Voltage (V) | AC 220V | |
| Load Power (W) | Depend | Solar Power (W) | 2500W | |
| Work Time (h) | 24 Hours |
Product Description
Inverter with charger:
Model: FD-IC-2500P
Inverter with charger function:
1. Overload shutdown
2. Over temperature shutdown
3. Low voltage alarm
4. Low voltage shutdown
5. High battery voltage shutdown
6. Short circuit protection
7. Polarity reverse connection protection
Inverter with charger features:
1. Automatic protection against overload
2. Over temperature and low/high battery conditions
Inverter with charger Application:
1. Household Appliances: compact microwave ovens, bread makers, food processors, small bar refrigerators, small vacuum cleaners, fluorescent and incandescent lights, sewing machines and fans
2. Power Tools: drills, jigsaws, sanders and buffers
3. Entertainment Electronics: televisions, VCRs, video games, stereos, musical instruments and satellite equipment
LED display shows output power and watt consumption
Inverter with charger specification:
Model No. | FD-IC-2500P | |||
Output | AC Voltage | 110V 120V 220V 230V 240VAC | ||
Rated Power | 2500W | |||
Peak Power | 5000W | |||
Waveform | Pure sine wave(THD<3%) | |||
Frequency | 50 or 60Hz(±2%) | |||
LED Indicator
| Green LED for power on | |||
Red LED Fault Status | ||||
Input | No Load Current Draw | <0.75A | <0.75A | |
DC Voltage | 12V / 24V / 48V | |||
Voltage Range | 10.5~15.0VDC / 21.0~30.0VDC / 42.0~60VDC | |||
Efficiency | about 90% | about 90% | ||
Charger | Max circuit charger | 12V | 20A | |
24V | 10A | |||
Feature | Automatic switching | |||
Protection | Bat. Low Alarm | 10.5V / 21.0V / 42.0VDC | ||
Bat. Low Shutdown | 10.0V / 20.0V / 40.0VDC | |||
Over Load | Shut off output voltage, re-power on to recover | |||
Over Voltage | 15.5+/-0.5V / 31.0+/-1V / 62.0+/-2VDC | |||
Over Temperature | Shut off output voltage, re-power automatically after temperature goes down | |||
Output Short | Shut off output voltage, re-power on to recover | |||
Environment | Working Temp. | 0~+40°C | ||
Working Humidity | 20% ~ 90% RH non-condensing | |||
Storage Tem. Humidity | -30°C~+70°C/22°F~+158°F | |||
Others | Dimension | 500×310×370mm(L×W×H) | ||
Packing | 14.5+/-0.5 kg | |||
Application | Home and Office appliances, Power tools and Portable equipment, Vehicle,Yacht and Solar power system… | |||
Inverter with charger workshop:
