Heavy Duty Solvent Printer (3.2m*6 heads Konica 512/42pl)
Negotiable
/ Set
1 Set(Min. Order)
- Shanghai
- T/T Credit Card
You May Like
-
Light duty Large Format Solvent Printer (3.2m /4 heads Konica 512/42pl)
-
Outdoor Solvent Printer (3.2m * 4 PCS Konica 512/42PL 1440DPI
-
konica flex printer (3.2m /6 heads Konica 512/42pl)
-
Heavy Duty Solvent Printer (3.2m /8 heads KONICA 512/42PL)
-
Heavy Duty Solvent Printer (3.2m /6 heads Konica 512/42pl)
-
Large Format Solvent Printer (3.2m /6 heads Konica 512/14pl)
Product Details
| Condition | New | Plate Type | Other, solvent printer | |
| Place of Origin | Shanghai, China | Brand Name | WER, WER | |
| Model Number | WER-K3206H, WER-K3206H | Usage | Other, poster printer | |
| Automatic Grade | Automatic | Gross Power | 2500 | |
| Dimensions(L*W*H) | 4.9m*0.81m*1.60m |
Product Description
Specifications
This outdoor printer is equipped with 6 pc of Konica 512/42pl head, 2 pass can print 40m2/h and resolution can reach 1440dpi max| Specification | Model: WER-K3206H |
| Print Technology | Drop on demand Piezo Head(Konica 512/42pl) |
| Print Head | 6 Heads (Konica 512/42pl) |
| Print Width | 3.2m width |
| Resolution | 1440dpi Max |
| Speed | 2pass 50m2/h, 180*720dpi |
| 2pass 40m2/h, 240*720dpi | |
| 3pass 19m2/h, 360*1080dpi | |
| Locating Mode | Raster/Servo motor |
| Media Width | 3.3m |
| Color | C M Y K Lc Lm |
| Ink Type | Special ink for Konica 512/42pl |
| Ink | Solvent based Pigment Ink, At least tow years outdoor |
| Ink delivery system | Ink force pumps auto supplying system , Main ink case 1L/color |
| Media Handle | Roll to Roll |
| Auto media feeding system | Infra Red Optical Controlling System is Equipped |
| Auto take-up system | Infra Red Optical Controlling System is Equipped |
| Dry system | Pre/Post and Middle heater controlled by PID |
| Media Type | PVC Vinyl, Flex banner, Carpet Paper, PVC Mesh Fabric, Perforated Vinyl, Cloth Banner Etc. |
| Motor | Step Motor |
| Linear Rail | THK / HLWIN |
| Height of Print-head | 1mm-10mm above media, Adjustable |
| Print head maintenance facility | Protection trays for auto purge, daily maintenance and print heads over night |
| Auto-cleaning system for print head | Double functional cleaning System of Pressure purge and Vacuum Suction |
| Interface | USB2.0 |
| Print Mode | Bidirectional Printing |
| File Format | TIFF,JPEG,Postscript 3,EPS,PDFRGB/CMYK |
| RIP Software | Original Maintop/Photoprint Rip software |
| Working Process | Maintop 5 software, Photoprint 6 software for Windows XP or Windows 7 Etc. |
| Power Supply | 50HZ/60HZ, 220V(±10%)>15A |
| Filtration Facility | PALL filter + Regular ink filter |
| Operation Environment | Temperature: 23°C~29°C; Humidity: 50%~80% |
| Packing Material | Wooden Case, No fumigation |
| Packing Dimension | 4.9m*0.81m*1.68m |
| Weight | 800kgs |
| Warranty | 1 Year |
| Certificate | ISO90001:2000 & CE |
