3.3 m wer-china WER-SD3404 large format outdoor solvent printer

Print Technology

Drop-On-Demand Piezo Electric

Print Head

4 Heads (Seiko/ Spt1020 - 35pl)

Print Width

3.3 m width

Resolution

1440 dpi Max

Print Speed

2 Pass 94 m2/h

3 Pass 70 m2/h

4 Pass 47 m2/h

6 Pass 35 m2/h

Locating Mode

Servo Driver/Servo Motor

Media Width

3.4 m

Color

C M Y K

Ink Type

Special ink for Seiko/ Spt1020 - 35pl

Ink

Solvent based Pigment Ink, at least two years outdoor durability

Ink delivery system

Negative pressure ink supply system, main ink case 1L/ color

Media Handle

Roll to Roll

Media feeding & take-up system

Infra Red Optical Controlling System for Media Feeding & Take-up

Dry system

Pre/ Post and Middle heater controlled by PID

Media Type

PVC Vinyl, Flex banner, Carpet Paper, PVC Mesh Fabric, Perforated Vinyl, Cloth Banner, etc.

Motor

Fuji AC Servo Motor

Linear Rail

HIWIN

Height of Print-head

2 mm - 4 mm above media, adjustable

Print head maintenance facility

Protection trays for auto purge, daily maintenance and print heads over night

Auto-cleaning system

Double functional cleaning System of Pressure purge and vacuum Suction

Interface

USB 2.0

Print Mode

Bidirectional Printing

File Format

TIF, JPEG, Postscript 3, EPS, PDFRGB/ CMYK

RIP Software

Original Maintop/ Photoprint Rip software

Working Process

Maintop software, Photoprint software for Windows 98 and Windows XP, etc.

Power Supply

50 HZ/ 60 HZ, 220 V ( ± 10 % ) > 15 A

Filtration Facility

PALL filter + Regular ink filter

Operation Environment

Temperature: 23% ~ 29%; Humidity: 50% ~ 80%
