Light Duty Solvent Printer (3.2m*8 heads Konica 512/42pl)
Negotiable
/ Set
1 Set(Min. Order)
- Shanghai
- T/T Credit Card
You May Like
-
Eco Solvent Printer 1.8m * 4 heads Konica 512-14pl
-
Eco Solvent Printer (1.8m*6 heads Konica 512-14pl)
-
3.3 m wer-china WER-SD3404 large format outdoor solvent printer
-
3.2m large format solvent outdoor printer spectra polaris print heads 512 15pl head solvent printer WER-P3208
-
5m solvent printer with 8 PCS Seiko SPT1020 35pl pvc banner printer
-
5m solvent printer with 8 PCS Seiko SPT1020 35pl flex printing machine
Product Details
| Condition | New | Plate Type | Other, Solvent printer | |
| Place of Origin | Shanghai, China | Brand Name | WER, wer | |
| Model Number | K3208L, K3208L | Usage | Other, print AD pictures | |
| Automatic Grade | Automatic | Gross Power | 2500 | |
| Dimensions(L*W*H) | 4.9m*0.81m*1.68m |
Product Description
Specifications
8 pc of Konica 512/42pl heads,2 pass can print 79m2/h
1440dpi max
AC servo motor,individual purge system,
Specification | Model: WER-K3208L |
| Print Technology | Drop on demand Piezo Head(Konica 512/42pl) |
| Print Head | 8 Heads (Konica 512/42pl) |
| Print Width | 3.2m width |
| Resolution | 1440dpi Max |
| Speed | 2pass 98m2/h, 180*720dpi |
| 2pass 79m2/h, 240*720dpi | |
| 3pass 38m2/h, 360*1080dpi | |
| Locating Mode | Raster/Servo motor |
| Media Width | 3.3m |
| Color | C M Y K |
| Ink Type | Special ink for Konica 512/42pl |
| Ink | Solvent based Pigment Ink, At least tow years outdoor |
| Ink delivery system | Ink force pumps auto supplying system , Main ink case 1L/color |
| Media Handle | Roll to Roll |
| Auto media feeding system | Infra Red Optical Controlling System is Equipped |
| Auto take-up system | Infra Red Optical Controlling System is Equipped |
| Dry system | Pre/Post and Middle heater controlled by PID |
| Media Type | PVC Vinyl, Flex banner, Carpet Paper, PVC Mesh Fabric, Perforated Vinyl, Cloth Banner Etc. |
| Motor | Step Motor |
| Linear Rail | THK / HLWIN |
| Height of Print-head | 1mm-10mm above media, Adjustable |
| Print head maintenance facility | Protection trays for auto purge, daily maintenance and print heads over night |
| Auto-cleaning system for print head | Double functional cleaning System of Pressure purge and Vacuum Suction |
| Interface | USB2.0 |
| Print Mode | Bidirectional Printing |
| File Format | TIFF,JPEG,Postscript 3,EPS,PDFRGB/CMYK |
| RIP Software | Original Maintop/Photoprint Rip software |
| Working Process | Maintop 5 software, Photoprint 6 software for Windows XP or Windows 7 Etc. |
| Power Supply | 50HZ/60HZ, 220V(±10%)>15A |
| Filtration Facility | PALL filter + Regular ink filter |
| Operation Environment | Temperature: 23°C~29°C; Humidity: 50%~80% |
| Packing Material | Wooden Case, No fumigation |
