Product Details
| Place of Origin | Guangdong, China | Brand Name | Chieta | |
| Model Number | DVB-T2-020 |
Product Description
Advantage
*Fully compliant with DVB-T2 standard
*MPEG-4 Decoded/H.264/MPEG-2
*High definition 1080P
*Stable performance ,LED display
HD TV Receiver DVB-T2
Product Description
* Fully compliant with DVB-T2 standard
* MPEG-2 MP@ML/ MPEG-4, H.264 SD& HD Decoding
* MPEG Layer 1& 2, Stereo Audio Decoding
* Supports AVI, MPG, VOB, MPEG, DIV, etc multimedia play formats
* Video resolution support: 1080P/ 1080i/ 720P/ 720i/ 576
* Multi language menu supported
* 1000 TV channels and radio programs available
* Supports USB upgrade, PVR playback
* Standard Electronic Program Guide(EPG)
* Supports multi-search function, including automatic/ manual/ list search
* Screen display ratio: 4:3 and 16:9
* Various channel editing function(Favorites, Move, Skip, Lock, and Delete)
* Switch power supply of AV 90-250V
Specification Detail
| Video | Decoder | 1. 1MPEG2 ISO/IEC 13818-2 MP@ML, |
| 2. H.264(MPEG4 part 10) main and high profile level 4.1/MPEG-2 MP@HL | ||
| Display Resolution | 1920×1080,1280×720,720×480 (i&p) | |
| Supported Videos | .avi, .mpg, .dat, .vob, .div, .mov, .mkv, .wmv, .flv, .ts | |
| Picture | Supported Picture | .jpg, .png, .bmp, .motion jpg |
| Supported Audio | .wma, .mp3, .wav, .aac, .ogg | |
| Audio | Decoder | MPEG-1 layerI/II,PCM downmix,IEC958 SPDIF |
| Mode | LEFT/RIGHT/STEREO/MONO | |
| Frequency | 32KHz,44.1KHz,48KHz | |
| Response | 20HZ~20KHZ +/-2Db | |
| TS Demux | Demultiplexer | MPEG2 ISO/IEC 13818-1 |
| Input Bit Rate | Max 100Mbit/s | |
| AV Output | Video Bandwidth | SD:5.0MHz(-3dB),HD:30MHz(-3dB) |
| Video Impedance | 75Ω | |
| Video Voltage Level | 1.0 Vp-p | |
| Audio Freq. Range | 20~20KHz | |
| Audio Impedance | 600Ω | |
| Audio Voltage Level | 2V rms(5.6Vp-p) | |
| Tuner | Input impedance | 75Ω |
| ANT Loop-Through | 51MHz~858MHz full Band loop through | |
| Input Frequency | 177.5~227.5MHz;474~858MHz; | |
| Input Level Range | 64QAM:-78.5dBm~-8.75dBm;16QAM:-84.1dBm~-8.75dBm;QPSK:-90.3dBm~-8.75dBm | |
| Environment | Power input voltage | DC5V, 50Hz/60Hz |
| Power Consumption | Max 12W | |
| Humidity | <95% | |
| Operation Temperature | 0°C~40°C |
Packaging & Shipping
| Unit Packing Size | PCS/ Carton |
| 190*180*45mm | 20 pcs |
| Carton CBM (0.03m3) | QTY per Container |
| 41*30*33 cm | 20GP: 12100pcs |
| Box Type | 40GP: 27000pcs |
| Color/ Neutral | 40HQ: 33000pcs |
| Unit Weight: | Carton Weight: |
| N/A | N/A |
OSD Menu View
