Chieta Multi DVB-S Universal Digital SatelliteTV Receiver With Various Style
- Zhuhai/Guangzhou/Shenzhen
- T/T Credit Card
You May Like
-
SD 195mm Design FTA DVB-S Digital Universal Satellite TV Receiver With AV S-video and RF Output
-
DVB-S SD Digital Satellite TV Receiver
-
Metal Housing White Charing Apprance DVB-S Digital Satellite TV Receiver With RS-232 Update Sofeware Function
-
Competitive Price Free To Air DVB-S Digital Satellite TV Receiver With Multi-function
-
Ali3329 Chipset Black Color Free To Air H.264 MPEG2 DVB-S Digital Satellite TV Receiver With Scart Output
-
SD Plastic Mould Design FTA DVB-S Digital Satellite Receiver With 2000 Channels for India
Product Details
| Place of Origin | Guangdong, China | Brand Name | Chieta | |
| Model Number | DVB-S 220mm Satellite |
Product Description
Advantage
*Universal digital Satellite TV receiver with multi-function
*Compatible with DVB-S/MPEG-2
*Support digital audio output
* Ultra-low threshold design
*Humanization OSD desigh,easy to operate
*Various style
Chieta Multi DVB-S Universal Digital SatelliteTV Receiver with Various Style
* Compatible with DVB-S/MPEG-2
* Ultra low threshold(<2.2dB)
* Storing 2000 channels
* Support dongle (optional)
* 9 PIP function
* Signal indicator available
* 0/22KHz function available
* DiSEqC 1.0,1.2function available
* PID settings available
* Software upgradable
* Power off memory
* Software upgradable via RS-232
* BOX-to-BOX upgrading function available
* With AV,S-Video and RF output
* Highly reliable ON/OFF power switch
Tuner | Frequency range | 950~2,150MHz |
Input level | -79~-11dBm | |
Input impedance | 75ohms | |
IF band width | 27~36MHz | |
Threshold | <2.2dB | |
Input interface | F-type | |
Audio | Audio output | L/R |
Frequency characteristic | <=+/-0.5dB(20Hz-20KHz) | |
Audio SNR | >=70dB | |
Level difference between left and right sound channels: | <=0.3dB(60Hz-18KHz) | |
Output connector | RCA | |
Video | Decode format | MPEG- |
Bit rate | <=15Mbps | |
Output mode | NTSC/PAL | |
Video output | 1V+/-20(mV)P-P | |
Resolution | 720x576(PAL),720x480(NTSC) | |
Channel decode | Demodulation mode | QPSK |
Symbol rate | 2~45Mbps | |
LNB power supply | 13/18V | |
Operating voltage | 80270V AC | |
Power | 20W(Max.) |
| Unit Packing Size | PCS/ Carton |
| 230*210*45mm | 20pcs |
| Carton CBM (0.06m3) | QTY per Container |
| 53.0*45.5*25.5 cm | 20GP: 9180pcs |
| Box Type | 40GP: 16390pcs |
| Color/ Neutral | 40HQ: 21310pcs |
| Unit Weight: | Carton Weight: |
| 720g | 15.5kg |
