new model 4X4 electric winch with 1000IBS

SC10.0X 12V or 24V

Heavy duty series wound motor, delivers high torque force.

Gears are made of 20CR steel, crafted with cold extrusion and heat treatment, to meet toughest pulling demand.

Bilateral roller brake, load-hold in two directions, offers more installation options.

360°rotating clutch makes engagement and disengagement much easier.

Precision machining transmission shaft lowers noises when winching.

Sealed winch body, well working in water.

Every winch is tested on pulling capacity and function.

Product Description

Rated line pull                                 10000lb (4536kg) single line

Motor                                                 6.0hp/4.5kw,series wound 12V

Control Remote switch                 12ft (3.7m) lead

Remote Control                              Included

Gear train                                         3 stage planetary

Gear reduction ratio                       230.4:1

Clutch                                               key way cam clutch

Braking                                             Automatic load-holding brake

Drum size                                       Ø63.5mm*L224mm

Cable                                               Ø9.1mm*28m

Fairlead                                           4-way roller fairlead

Wireless Remote control            Optional

Battery recommended 650 CCA minimum for winching

Battery leads 2 gauge, 72" (1.83m)

Finishing Black, dark grey coating

Overall dimension ( L*W*H) 525*160*214mm

Mounting bolt pattern 254*114.3mm

SC10.012V or 24V

Heavy duty series wound motor, delivers high torque force.

Gears are made of 20CR steel, crafted with cold extrusion and heat treatment, to meet toughest pulling demand.

Bilateral roller brake, load-hold in two directions, offers more installation options.

360°rotating clutch makes engagement and disengagement much easier.

Precision machining transmission shaft lowers noises when winching.

Sealed winch body, well working in water.

Every winch is tested on pulling capacity and function.

Product Description

Rated line pull 10000lb (4536kg) single line

Motor 6.0hp/4.5kw,series wound 12V

Control Remote switch 12ft (3.7m) lead

Remote Control Included

Gear train 3 stage planetary

Gear reduction ratio 230.4:1

Clutch key way cam clutch

Braking Automatic load-holding brake

Drum size Ø63.5mm*L224mm

Cable Ø9.1mm*28m

Fairlead 4-way roller fairlead

Wireless Remote control Optional

Battery recommended 650 CCA minimum for winching

Battery leads 2 gauge, 72" (1.83m)

Finishing Black, dark grey coating

Overall dimension ( L*W*H) 525*160*214mm

Mounting bolt pattern 254*114.3mm
