Product Details
| Place of Origin | Guangdong, China | Brand Name | UNI-T | |
| Model Number | UT805A | Measuring Current Range | 10A | |
| Measuring Voltage Range | 1000V | Measuring Resistance Range | 20MΩ | |
| Measuring Capacitance Range | 6mF | Operating Temperature | -40°C - 1000°C | |
| Dimensions | 300mm * 245mm * 105mm |
Product Description
Bench Type Digital Multimeters UNI-T UT805A automatic range True Valid Values average value display
Detailed
UT805A is a 200000 count digital bench-type multimeter designed with large-scale integrated analog/digital circuit, micro-processing technology, 24-bit A/D converter, operational amplifier, and True RMS display. UT805A
is digitally calibrated to ensure high accuracy and reliability. It’s capable to test DC/AC Voltage, current, resistance, diode, circuit continuity, capacitance, and frequency; the memory recall function makes all your
tasks easier. UT805A has RS232C and USB port for easy connection with computer to realize macro record and monitoring of transient dynamic data.
UT805A complies with IEC61010 standard, CATI 1000V, CATII 600V.
Contrast
| Specifications | Range | Best Accuracy |
| Model | UT805A | |
| DC Voltage (V) | 200mV/2V/20V/200V/1000V | ±(0.015%+3) |
| AC Voltage (V) | 200mV/2V/20V/200V/750V | ±(0.2%+100) |
| DC Current (A) | 2mA/200mA/10A | ±(0.03%+10) |
| AC Current (A) | 2mA/200mA/10A | ±(0.3%+100) |
| Resistance (Ω) | 200Ω/2kΩ/20kΩ/200kΩ/2MΩ/20MΩ | ±(0.02%+6) |
| Capacitance (F) | 6nF/60nF/600nF/6μF/60μF/600μF/6mF | ±(2%+5) |
| Frequency (Hz) | 10Hz~60MHz | ±(0.1%+3) |
| Features | ||
| Display Count | 200000 | |
| Auto Range | √ | |
| True RMS | √ | |
| Bandwidth (Hz) | 100kHz | √ |
| Diode | √ | |
| Continuity Buzzer | √ | |
| Data Hold | √ | |
| Relative Mode | √ | |
| MAX/MIN | √ | |
| Data Logging | 100 | |
| Data Recall | √ | |
| RS-232 | √ | |
| USB Interface | √ | |
| LCD Backlight | √ | |
| Dot-matrix Liqid Crystal Display | 256×64 Pixels | √ |
| Setup | √ | |
| Input Protection | √ | |
| Input Impedance for DCV | 2V Range: Around 10GΩ, All Other Ranges: Around 10MΩ | √ |
| Voltage &Current:AC+DC Measurement | √ | |
| General Characteristic | ||
| Power | AC 220V/50Hz | |
| LCD Size | 128mm × 28mm | |
| Product Color | Red and Grey | |
| Product Net Weight | 3.2 Kg | |
| Product Size | 300mm × 245mm × 105mm | |
| Standard Accessories | Test Lead, AC 220V Power Cord, RS-232 Interface Cable, USB Interface Cable, PC Software CD, Alligator Clip, Multi-Purpose Socket, Test line | |
| Standard Individual Packing | Gift Box, English Manual | |
| Standard Quantity Per Carton | 4 PCs | |
| Standard Carton Measurement | 685mm×450mm×315mm (0.097 CBM Per Standard Carton) | |
| Standard Carton Gross Weight | 19.2 Kg | |
Fitting
1. Test Lead,
2. AC 220V Power Cord,
3. RS-232 Interface Cable,
4. USB Interface Cable,
5. PC Software CD,
6. Alligator Clip,
7. Multi-Purpose Socket,
8. Test line
