Home > Products > Electrical Instruments > UNI-T UT70A Modern Digital Multi Purpose Meter LCD Handheld Multimeter Multi Use Tester ac dc Volt Amp Ohm Capacitance Tester

UNI-T UT70A Modern Digital Multi Purpose Meter LCD Handheld Multimeter Multi Use Tester ac dc Volt Amp Ohm Capacitance Tester

FOB Price

USD $30 - $50 / Piece

1 Piece(Min.Order)

Supply Ability 500 Piece / Pieces per Month
Port Shenzhen
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	UNI-T
Model Number	ut70a	Measuring Current Range	20mA- 10A
Measuring Voltage Range	2-0mV-1000V	Measuring Resistance Range	200Ω - 200MΩ
Measuring Capacitance Range	20nF/100μF	Measuring Inductance Range	2mH-20H
Operating Temperature	-40 °C - 1000°C	Dimensions	195mm90mm40mm

Product Description

UNI-T UT70A Modern Digital Multi Purpose Meter LCD Handheld Multimeter Multi Use Tester ac dc Volt Amp Ohm Capacitance Tester

Introduction

UT70A is a handheld electric bridge multimeters, the advanced product design, functional and stable performance, institutional trendy, large screen display, can be used to measure AC and DC voltage and current, resistance, capacitance, inductance, temperature, frequency, diode forward buck, transistor hFE and sound off,; logic level and has a data hold and maximum hold function (in low light places also provide backlight screen)

Specification

Specifications	Range	Best Accuracy
Model		UT70A	UT70B
DC Voltage (V)	200mV/2V/20V/200V/1000V	±(0.5%+1)
DC Voltage (V)	400mV/4V/40V/400V/1000V		±(0.8%+1)
AC Voltage(V)	200mV/2V/20V/200V/750V	±(0.8%+3)
AC Voltage(V)	4V/40V/400V/750V		±(1%+5)
DC Current (A)	20mA/2mA/200mA/10A	±(0.8%+1)
DC Current (A)	400mA/4000mA/40mA/400mA/10A		±(1%+2)
AC Current (A)	20mA/2mA/200mA/10A	±(1%+3)
AC Current (A)	400mA/4000mA/40mA/400mA/10A		±(1.5%+5)
Resistance (Ω)	200Ω/2kΩ/20kΩ/200MΩ/2MΩ/20MΩ/200MΩ	±(0.8%+1)
Resistance (Ω)	400Ω/4kΩ/40kΩ/400kΩ/4MΩ/40MΩ		±(1%+2)
Capacitance (F)	20nF/200nF/2μF/100μF	±(2.5%+5)
Capacitance (F)	4nF/40nF/400nF/4μF/40μF/400μF/4μF/40μF		±(4%+3)
Inductance	2mH/20mH/200mH/20H	±(2%+10)
Frequency	2kHz~10MHz	±(0.1%+3)
Frequency	4kHz/40kHz/400kHz/4MHz/40MHz/400MHz		±(0.1%+3)
Temperture(°C)	-40℃~1000℃	±(1%+3)	±(1%+3)
Temperture(°F)	-40℉~1832℉	±(1%+4)	±(1%+4)
RPM	40kRPM		±(0.1%+3)
Features
Fused 10A Range		√	√
Diode		√	√
Transistor		√
Continuity Buzzer		√	√
Relative measurement			√
Relative Mode	TTL	√
Full Icon Display		√	√
Sleep Mode		√	√
Low Battery Display		√	√
Input Impedance for DC Voltage Measurement	10MΩ	√	√
Max/Min Mode			√
Peak Hold		√
Data Hold		√	√
Display Backlight		√	√
Auto Ranging		√	√
Max. Display		1999	3999

RS232			√
Analog Bar Graph	41		√
General Characteristic
Power	9V Battery (6F22)
LCD Size	62mm×53mm
Product Color	Red and Grey
Product Net Weight	600g (including holster)
Product Size	195mm×90mm×40mm
Standard Accessories	UT70A-Test Lead, Battery, English Manual, Point Contact Temperature Probe, Test Clip, Multi-Purpose Socket, Holster
Standard Accessories	UT70B-Test Lead, Battery, English Manual, Point Contact Temperature Probe, Test Clip, RS232C Interface Cable, Software, Holster
Standard Packing	Gift Box, English Manual
Standard Quantity Per Carton	20Pcs
Standard Carton Measurement	535mm×362mm×385mm(Around 0.074 CBM Per Standard Carton)
Standard Carton Gross Weight	UT70A-22.7kg,UT70B-20kg
Optional Accessories*	Clip-On Test Lead Light (UT-TL), Built-In Test Lead Light (UT-L1), Built-In Test Lead Light Plus (UT-L2), Carrying Bag

Accessory

1. Test Lead,
2. Battery,
3. English Manual,
4. Point Contact Temperature Probe,
5. Test Clip,
6. Multi-Purpose Socket,
7. Holster.
8. Clip-On Test Lead Light (UT-TL), *
9. Built-In Test Lead Light (UT-L1), *
10. Built-In Test Lead Light Plus (UT-L2), *
11. Carrying Bag*
