Home > Products > Electrical Instruments > UNI-T UT136D Handheld Auto-ranging Digital Multimeters Data Hold LCR Meter AC DC Frequency Resistance automatic range multimeter

UNI-T UT136D Handheld Auto-ranging Digital Multimeters Data Hold LCR Meter AC DC Frequency Resistance automatic range multimeter

FOB Price

USD $1 - $15 / Piece

5 Pieces(Min.Order)

Supply Ability 500 Piece / Pieces per Month
Port Shenzhen
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	UNI-T
Model Number	UT136D	Measuring Current Range	400uA-10A
Measuring Voltage Range	400mV-500V	Measuring Resistance Range	400Ω-40MΩ
Measuring Capacitance Range	4nF-100uF	Operating Temperature	-40 °C - 1000°C
Dimensions	72mm137mm35mm

Product Description

Handheld Auto-ranging Digital Multimeters UNI-T UT136D Data Hold LCR Meter AC DC Frequency Resistance automatic range multimeter

Introduction

UT136 series are mini handheld auto-ranging digital multimeters that offer users complete functions, stable performance, low power consumption, novel structural design, high degree of safety and reliability, and therefore become an ideal portable tool for maintenance and repairing.

Applicable fields are homes, schools, metallurgy, communications, manufacturing, national defense, electric power, chemical industry, ect, and the series is a best choice for electric circuit/equipment maintenance and repairing.

Specification

Specifications	Range	Best Accuracy
Model		UT136A	UT136B	UT136C	UT136D
DC Voltage	400mV/4V/40V/400V/500V	±(0.8%+1)	±(0.8%+1)	±(0.8%+1)	±(0.8%+1)
AC Voltage	400mV/4V/40V/400V/500V	±(1.2%+3)	±(1.2%+3)	±(1.2%+3)	±(1.2%+3)
DC Current	400uA/4mA/40mA/400mA/4A/10A	±(1.0%+2)	±(1.0%+2)	±(1.0%+2)	±(1.0%+2)
AC Current	400uA/4mA/40mA/400mA/4A/10A	±(1.2%+5)	±(1.2%+5)	±(1.2%+5)	±(1.2%+5)
Resistance	400Ω/4000Ω/40kΩ/400kΩ/4MΩ/40MΩ	±(1.0%+2)	±(1.0%+2)	±(1.0%+2)	±(1.0%+2)
Capacitance	4nF/40nF/400nF/4uF/40uF/100uF		±(4.0%+3)
Temperature	‘-40~1000			±(2.5%+3)
Frequency	10Hz/100Hz/1kHz/10kHz/100kHz/1MHz/10MHz	±(0.5%+3)	±(0.5%+3)	±(0.5%+3)	±(0.5%+3)
Duty Cycle	0.1%-99.9%	√	√	√	√
Features
Diode		√	√	√	√
Continuity Buzzer		√	√	√	√
NCV					√
Auto Power Off		√	√	√	√
Low Battery Display		√	√	√	√
Input Impedance for Voltage Measurement	≥10MΩ	√	√	√	√
Data Hold		√	√	√	√
Max. Display		3999	3999	3999	3999
General Characteristic
Power	9VBattery(6F22) (not included)
LCD Size	49mm×18mm
Product Color	Red +Grey
Product Net Weight	About 200g (Battery included)
Product Size	72mm×137mm×35mm
Standard Accessories	Test leads, Battery, Point type temperature probe(UT136C Only)
Standard Packing	Giftbox, English Manual
Standard Quantity Per Carton	66 Pcs
Standard Carton Measurement	595mm×310mm×350mm
Standard Carton Gross Weight	About 22 Kg

Accessory

1. Test leads,
2. Battery (not included)

(JulieZhou)
