UL flat CABLE PV wire 10AWG for solar energy
- 200000 Meter / Meters per Month
- ningbo
You May Like
-
UL flat CABLE pv wire 8AWG black for soalr power system
-
UL flat cable 14AWG black xlpe power cable for solar system
-
14awg UL flat cable for solar power system
-
UL 854/ UL 4703 approved 10awg solar pv cable for solar power system
-
UL 854/ UL 4703 approved 12awg solar pv cable for solar power system (China suppilier)
-
UL approved PV wire solar cable 12awg
Product Details
| Place of Origin | Zhejiang, China | Brand Name | Benyang | |
| Model Number | UL 10awg | Insulation Material | XLPE | |
| Type | Low Voltage | Application | Other, Solar System and Power Station | |
| Conductor Material | Other, Tinned Copper | Jacket | Other, XLPE |
Product Description
1.Application
FOLLOWRAY SOLAR CABLE Used for interconnection wiring of grounded and ungrounded photovoltaic power systems and other applicable parts of the National Electrical Code (NEC), NFPA 70.
2.Cable design
1.Conductor: fine wire strands of tinned copper wires,according IEC 60228,Class 5
2.Insulation:Flame retardant PE,electron beam cross-linked
Colours: black
3.Outer jacket: Flame retardant PE,electron beam cross-linked
resistance against water , UV resistant
3.Temperature range
Max,temperature at conductor -40°C up to +120°C
Temperature range -40°C up to +90°C(min.25 years)
4.Electrical characteristics
Nominal AC voltage 600V
AC-test-voltage 3.0KV(14AWG~10AWG)
5.Marking
(UL) E326179 PV WIRE 14~6AWG 90°C WET OR DRY 600V SUN RES -40°C NINGBO FOLLOWRAY SOLARTECH CO . , LTD.
6.Industry Standards
UL 4703 , File No. E326179
Packaging: Carton/ Pallet
Shipping: Within 15 days
1. Response within 12 hours
2. Strict quality control system.
3. Faster lead time than our competitors.
4. Excellent quality with reasonable price.
5. Strong technical support (technical data, drawing, etc.)
6. Cable solutions to your particular requirements.
7. Free sample is available with economic express fee.
8. 12 months quality guarantee after delivery.
