Home > Products > Heat detector > 24V Conventioal Linear Explosion proof heat detector
24V Conventioal Linear Explosion proof heat detector
- Shenzhen China
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | P&H | |
| Model Number | H64-2 |
Product Description
Specifications
heat detector for firelow power consumption
2 wire 24V, Fixed and Rate of rise Temperature
OEM available
Delivery on time
Product description
Name
Heat detector
24V Conventioal Linear Explosion proof heat detector
Features
1.Moden Stylish design
2.Low Power consumption 1.Moden Stylish design
3.Remoted LED indicator output(2 wire)
4.Non-polar input power supply
5.Extended warranty
6.Easy Installation and maintenance
Characteristic
Dual LEDs for 360-degree visibility
Twist-off mounting for fast installation
Technical Data
| Model | H64-2 | H64-4 |
| Operating Voltage | DC9~35V | |
| Standby Current | 55uA | 12mA(NC), 500uA(NO) |
| Alarm Current | 35mA@DC12V, 83mA@DC24V | 3mA(NC), 19mA(NO) |
| Alarm Output | Conventional alarm output & LED flash | Relay output and LED flash |
| Smoke Alarm Density | 2.06%/ft | |
| Installation Method | Ceiling Mounted | |
| Operating Temperature | -10°C ~ +55°C | |
| Operating Humidity | 95%RH(max) | |
| Dimensions | 100mm(Dia)x48mm(H) | |
Ordering Information
| Model | Detail |
| H64-2-FH | 2 wire Fixed Temperature(57 °C ,135F)heat detector |
| H64-2-RH | 2 wire Rate of Rise (8-15 °C /min)heat detector |
| H64-2-FRH | 2 wire Fixed Temperature (57 °C ,135F) & Rate of Rise (8-15 °C /min)heat detector |
| H64-4-FH | 4 wire Fixed Temperature(57 °C ,135F)heat detector |
| H64-4-RH | 4 wire Rate of Rise (8-15 °C /min)heat detector |
| H64-4-FRH | 4 wire Fixed Temperature (57 °C ,135F) & Rate of Rise (8-15 °C /min)heat detector |
Product view Heat detector
