BFQ-600 /800/ 1000Surface-rolling Type Slitting & Rewinding Machine
- NINGBO
You May Like
Product Details
| Type | Other | Application | 600/800/1000 | |
| Place of Origin | Zhejiang, China | Brand Name | GUO TAI | |
| Model Number | BFQ600/800/1000 | Dimensions | 600MM |
Product Description
Surface-rolling Type Slitting & Rewinding Machine
Performance and Features:1. The main motor adopts imported variable frequency speed regulating.
2. Unwinding adopts magnetic powder brake tension and automatic deviation-rectifying.
3. Automatic meter counting and meter number setting for automatic stop.
4. Double air inflatable unwinding shaft can replace material quickly.
5. Material rolling adopts dead-weight type surface rolling.
Main Technical Variables:
Type | BFQ-600 | BFQ-800 | BFQ-1000 |
Max. Width of Mother Roll | 600mm | 800mm | 1000mm |
Max. Diameter of Mother Roll | 600mm | 600mm | 600mm |
Width of Final Roll | 20~600mm | 20~800mm | 20~1000mm |
Slitting and Rewinding Speed | 5~120m/min | 5~120m/min | 5~120m/min |
Tolerance of EPC | <±0.5mm | <±0.5mm | <±0.5mm |
Total Power | 2.2Kw | 3 Kw | 3 Kw |
Weight of Machine | 1200kg | 1400 kg | 1600 kg |
Overall Dimension | 1900×1000×1300mm | 2300×1000×1300mm | 2500×1000×1300mm |
