Automobile Inner Accessories Vacuum Forming Machine
- Nanjing .Shanghai or NIngbo
- T/T
You May Like
Product Details
| Place of Origin | Anhui, China | Brand Name | SUNMINE | |
| Condition | New | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
The machine with 3 Working Station is applied to producing automobile dashboard or automobile door panel, which is available for coiled materials.
It mainly consists of loading station, heating station, forming station, etc.
Working procedure: loading, auto-pressing, heating, blowing, forming, cooling, unloading, etc.
It adopts followings technologies: efficient heating, infrared measurement for temperature, hydraulic proportional controlling. The machine is featured by fully automatical, easy to operate, highly efficient, etc.
Usage | To form interior liners of automobiles. |
Customized | Yes |
Forming Area | Max. 2200mm×1200mm. |
Forming Depth | Max. 350mm. |
Thickness of Sheet | 1.0mm~3.5mm |
Cycle Time | ≤80 seconds/piece |
Heating Power | About 145Kw |
Total Power | About 170Kw (380V, 50Hz) |
Total Air Volume | ≥2cbm/min(0.5Mpa~0.65Mpa) |
Labor Required | 1 |
Prevailing Color | Grey; Green. |
