Factory Sale Reasonable Price Conveyor Belt Dryer Conveyor Dryer

Specifications

Factory sale reasonable price conveyor belt dryer conveyor dryer

Conveyor dryer

Delivery site of conveyor dryer

Introduction of conveyor dryer

Conveyor dryer is also named as mesh belt dryer. It is mainly used to dry up ball shape/oval

shape/pillow shape/egg shape/pieces shape fruits, mushroom, coal or charcoal briquettes.

Raw material is conveyed to mesh through belt conveyor. Raw material are evenly distributed

on the mesh, and through mesh conveyor's moving, hot air is conveyed from the heater to

conveyor dryer. Each conveyor dryer has 3-5 layers mesh, raw material moves from the top

layer to the lowest layer. Moving speed of conveyor layer can be adjusted according to your

production capacity and final coal/charcoal briquette's water content.

Inner structure of conveyor dryer

Conveyor dryer consists of drying section, transmission device, discharging pipe, mesh belt,

draught fan, etc.

Working principle of conveyor dryer

Main working principle of conveyor dryer is to put the material evenly spread in the network,

the transmission device drag moving back and forth inside the drying machine, hot air in the

materials passing through, the water vapor from the eduction in the platoon is wet hole, so

as to achieve the purpose of drying. 12-60 conveyor mesh belt with steel wire mesh belt,

body length is made up by the standard section, in order to save space, conveyor dryer

can be made into multi-layer type, there are two common room three, two room five layers,

length, 6-40 m, effective width 0.6- 3.0 m.

Characteristics of conveyor dryer

1) In order to get perfect drying effect, our conveyor dryer can adjust the air volume, heating

temperature, mesh belt moving speed.

2) Conveyor dryer is flexible.

3) Conveyor dryer is energe saving dryer. The heating air can be recycles to use.

4) Conveyor dryer can use various type heat resource.

Parameter of conveyor dryer

Customer show

If you are interested in our conveyor dryer, warmly welcome to contact me!

 Lantian Mechanical Plant

 Lantian Mechanical Plant is founded in 1980s, it is a professinoal dryer making factory.

Our main dryer includes mesh dryer, vertical dryer, rotary dryer, box dryer, mesh belt dryer,

conveyor mesh belt dryer, conveyor dryer, etc. Through over 28 years' making experience,

our conveyor dryer has been widely exported to different countries. Such as Afghan, Iran,

Egypt, Dubai, Russia, Korea, Vietnam, Thailand, etc.

CE and ISO certificates
