Reasonable Price Factory Sale Caly/sand/clay/slag Rotary Silica Sand Dryer

Specifications

 Reasonable price factory sale caly/sand/clay/slag rotary silica sand dryer

Silica sand dryer

Work site of silica sand dryer

Introduction of silica sand dryer

1.New type silica sand dryer with new type heat pipe structure, give material an indirect

heated dryer.

2. Under the traction of hot air blower,enter and heating heat pipe,heat pipe heat transfer

to the material,due to material and heat pipe to full contact,so the drying out of material to

is better than common rotary kiln dryer's drying effect of the market.

3. The new type rotary kiln dryer's device enables real-time water vapor emitted from the

top, and the end of the steam heat recovery and utilization,is a new type high efficient

energy- saving drying equipment.

4. New type silica sand dryer is based on over 28 years' experience, independent of

the development and production of a new type of high efficiency energy - saving drying

equipment.

5. Silica sand dryer uses heat pipe indirect to materials heating, materials and heat

source to full contact, steam to real- time from the top of device , heat source use hot -

blast stove heating not consumption, with dry effect good, and structure reasonable,

and output big, and energy consumption low, and install convenient, and operation

simple, and to range wide such as advantage of, is feed such as powder materials

the most ideal private device.

Features of silica sand dryer

1. Within the device is composed of dozens to hundreds of heat pipes materials enter

from the top of the heating duct fell after drying the bottom of the device,get to the bottom

will be hot after shave plate scraped the bottom of the tube material keeps contact with

heat pipe to have a drying effect. This can greatly improve thermal contact area and

utilization of the material.

2. The device has wet discharging device in the drying process can be a result of discharge

large amounts of water vapor in the first time, the complete separation of water vapor drying

faster the lower heat loss, because it avoids the material in the process of drying and water

vapour exposure to eliminate the material may not be caused by repeated drying of moisture

absorption.

3.Tail of air circulator,we can heat reuse of tail up into a dryer really do make full use of heat

to achieve energy - saving effect.

Raw material of silica sand dryer

1) Wood sawdust, wood chip, wood shavings, etc.

2) Coal powder, coal slurry, coal waste, etc.

3) Clay, slurry, sand, silica sand, etc.

4) Grain, such as wheat, rice, etc.

5) Mash, diatillers, etc.

6) Animal dungs.

Structure of silica sand dryer

Silica sand dryer consists of seven parts: they are feeding hopper, heat source, rotary

drum, lifting board, draught fan, unloader.

Features of silica sand dryer

1. Large production capability, continuous operation

2. Simple structure, convenient operation

3. Low malfunction, low maintenance cost.

4. Wide scope of application, can be used to dry the granular materials, favorable for those

materials with the big adhesion.

5. Great operating flexibility, the output of the products allows a larger fluctuation range, not

influencing the quality of the products.

6. High thermal efficiency(≥ 60%)

7. Medium temperature in outlets(about700 degree)

8. Alloy steel plate or stainless lifting plate

9. Guaranteed drying effect (≤ 5% after drying)

10. Final wood sawdust's humidity can be adjusted by adjusting its speed.

11. Far-ranging raw material: such as wood sawdust, wet sand, clay, coal, etc.

Main parameter of silica sand dryer

Customers came to our factory to check our silica sand dryer

Delivery site of silica sand dryer

If you are interested in our silica sand dryer, please contact:

In order to provide you the most suitable silica sand dryer, could you share

me the following details? Thanks!

1) What's your raw material?

2) How many kilograms raw material do you want to dry up per hour?

3) What's your raw material's dimension?

Our factory:

FAQ of silica sand dryer

1. What the silica sand dryer can be used for ?

Silica sand dryer can dry many kinds of granules materials which contain moisture,

such as coal, coal slurry, slag, industrial waste, clay, sand, cow dung, chicken dung,

grain, etc. They are widely used in building materials, metallurgy, chemical industry.

2. Is the silica sand dryer's heating source directly contact with clay?

Silica sand dryer's heating source can provide about 700-800℃, so it will be very

dangerous if hot air directly contact the dry raw material. In order to avoide this, our

rotary kiln dryer has designed a special equipment to avoide hot spark enters into

rotary drum.

3. Can I use the coal or gas as the heating source?

Yea, you can use coal, gas, electricity, oil and wind power to heat the silica sand dryer.
