Home > Products > YJ62 Shaded Pole Motor > Small electric motors Fan motor Electrical motor Shaded Pole Motor YJ62-20 for Oven, Electric fan, Humidifier,Heater, Fireplace
Small electric motors Fan motor Electrical motor Shaded Pole Motor YJ62-20 for Oven, Electric fan, Humidifier,Heater, Fireplace
- Shenzhen
- T/T
You May Like
-
Electric fan motor Asychronous motor Electrical motor Shaded Pole Motor YJ62-20: 230V,50hz,22w, 2000-2500rpm,<43dB,CL.B
-
Electric motor Single phase 50hz 220v YJ62-30:air pump motor ac shaded pole motor
-
Air compressor Nebulizer motor Oxygen Concentritor motor: SP AC motor 230V 50/60Hz UL/CE certified
-
110V blower motor Air compressor nebulizer motor Electric motor Shaded Pole Motor YJ62-30: 127/230V, 60hz, high quality motor
-
Small powerful electric motors YJ62-30: 120/220v, 50/60hz, Insulation class A/E/B/F/H,2500-3000rpm,electric motor specifications
-
230V 50/60 Hz shaded pole motor, high pressure, steady operation,low noise Piston Nebulizer Motor
Product Details
| Brand Name | Zhaoli Motor | Model Number | YJ62-20 | |
| Type | Asynchronous Motor | Frequency | 50HZ | |
| Output Power | 5-100W | Protect Feature | Other, Rust-proof | |
| Phase | Single-phase | Certification | CCC, CE, ROHS, UL, VDE, Other, CCC, CE, ROHS, UL, VDE, CUL | |
| AC Voltage | 208-230 / 240 V | Place of Origin | Guangdong, China |
Product Description
Specifications
Rated Voltage:100-240VACLaminations: 8--25mm
Size: 62.5*62.5mm
Life: 5000-10000 Hours
Single Phase Shaded Pole motor is mainly composed of core, primary and secondary windings, rotor, stator and bobbin. Secondary winding is the short-circuiting ring, producing magnetic potential and forming a rotating magnetic field in the air gap. Rotor is made up of core and squirrel cage conductor. The function of squirrel cage conductor is to induce current and electromagnetic torque, realizing the conversion of electricity and motion energy.
Product General Performance Parameters:
Voltage----------------------100-240VAC
Frequency-------------------50/60HZ
Power------------------------5-100W
Insulation Class----------- -A/E/B/F/H
Noise--------------------------less than 43Db(A)
Life----------------------------5000-10000Hours
Core Thickness---------------8-40mm
Shaft Diameter(mm)---------Φ2.5,Φ3.17,Φ4.0,Φ4.6,Φ5.0,Φ5.5,Φ6.0,Φ6.35
Series: YJ62-20
Characteristics:
Low noise, Stable operation, Long life, No electromagnetic interference, Less maintenance.
Application:
Ventilator, Nebulizer, Vacuum pump, Air pump
