Heat Polyester Shrinking Tape for Binding
- Tianjin Qingdao shanghai Ningbo
- T/T Money Gram Credit Card
You May Like
Product Details
| Place of Origin | China | Brand Name | New Light | |
| Model Number | heat shrinkable tape | Type | Other, insulation tape | |
| Material | Other, polyester | Application | Other, High Voltage, used for motor winding and insulation binding |
Product Description
Specifications
SpecificationsWidth: 10-50mm
Thickness: 0.10mm,0.15mm,0.20mm,0.25mm,30mm
Used for motor winding and insulation binding.
Insulating heat shrinking polyester fiber tape
Discription: The product is made from polyester fiber, it has excellent heat and insulation property and high mechanical strength,high shrinkage properties,
applicable to the motor and winding insulation binding. After binding and dried at 105ºC for 10 minutes, it will be shrunk to 70%, which is good at a solid binding and at a compatibility with transformers. It will be utilized in the transformer oil at 105ºC for a long time.
Width:10-50mm
Thickness: 0.10mm,0.15mm,0.20mm,0.25mm,30mm
Shrinkage rate: ≥15%-45%
Characteristics: tensile strength≥200N/10mm
Color: white, Colour line in the middle is available on request
Application: polyester heat shrinkable tape can be used as insulation binding materials for motors and transformers.It can be used in transformer oil at 105 degree for long time.
