2841-W Modified Polyester Resin Impregnated Fiberglass Web Binding Tape
- Tianjin Qingdao shanghai Ningbo
- T/T Credit Card
You May Like
Product Details
| Place of Origin | China | Brand Name | New Light | |
| Model Number | 2841 | Type | Other, insulation tape | |
| Material | Other, fiberglass | Application | High Voltage |
Product Description
Specifications
Specification:1.Thickness:0.17- 0.30mm
2.Width :10-50mm
3. Length:100-250m/pancake
2841-W Modified Polyester Resin Impregnated Fiberglass Tape
1. Description: 2841-W Modified Polyester Resin Impregnated Fiberglass Tape are of high quality,which consist of parallel twisted E-glass yarns preimpregnated with a special thermosetting polyester resin .
2. Specification:
A.Thickness:0.17- 0.30mm
B.Width :10-50mm
C. Length:100-250m/pancake
D. Storage time: 3- 12 months
Application 1,Banding tape should be stored in the condition of room temperature. If environment temperature is above 30degree, the products should be put in the freezer. 2,The testing of properties (for example: test volatile content) should be carried within one hour after the banding tape is taken from the plastic bag. 3,When apply the banding tape, keep it in the plastic bag at the room temperature for 24 hours after taking out from the freezer. 4,During the process of application, uneven tension and unsmooth banding would make the tape separation. You could continue to use after neatening the remaining pancake.
| Curing cycles: | |||||
| Temperature (°c) | 160 | 150 | 135 | 120 | 115 |
| Time (hour) | 3 | 3.5 | 6 | 15 | 24 |
Model No. | Name | Temp. |
2841-W | Modified polyester resin impregnated fiberglass web binding tape | F(155°C) |
| Type | 2850-W | 2841-W | 2830 |
| Thermal class | H | F | B |
| Volatile content | ≤5% | ≤5% | ≤5% |
| Loss of weight at calcination | 27%±2% | 27%±2% | 27%±2% |
| Soluble resin content | ≥90% | ≥90% | ≥90% |
| Tensile strength before curing | ≥1000N/cm | ≥1000N/cm | ≥500N/cm |
| Maximum pull while banding | 800N/cm | 800N/cm | 800N/cm |
