Mine Drilling Rig
- shenzhen shanghai guangzhou
- T/T
You May Like
Product Details
| Condition | New | Type | Other, Core Drilling Rig, Drilling Rig | |
| Power Type | Diesel | Place of Origin | Hunan, China | |
| Brand Name | FLYDISC | Model Number | HGY-650 | |
| Usage | Coal | Voltage | 220v | |
| Power(W) | 30kw | Dimension(L*W*H) | 2400*1020*1700 | |
| Weight | 1550kg | Certification | ce/ISO9001:2008 | |
| Warranty | 6 months | After-sales Service Provided | Overseas service center available |
Product Description
mine drilling Rig 650m
Brief introduction of Mine drilling Rig :
1.32 years professional manufacture
2. Certificate: ISO9001:2008
3. Export to: Africa, the Middle East, South America, Asia,
Countries: South Africa, Zambia, Sudan, Iran, South Korea, Costa Rica etc.
Features of mine drilling Rig :
1) Compact in structure and light in weight.
2) High reliability, good performance and durability.
3) Common auto parts, such as clutch, transmission case and shifting structure.
4) Safe and reliable operations with synchronizer for shifting while the rig is running.
5) Be attached to the tower.
Use of mine drilling Rig : for geotechnical investigation, exploring, prospecting, water well drilling;
Widely used in the construction of the projects e.g. prospection, railway, road, port, bridge, water conservancy and hydropower, tunnel, well, industrial and civil construction, geological exploring, large diameter boring pile and small diameter diamond core deep hole drilling, etc.
Technological Data of mine drilling Rig
Model | HGY-650 mine drilling Rig |
Drilling depth( m) | 650 |
Spindle speed( r/min) | Positive rotation rate: 65 117 201 309 440 187 338 582 894 1273 Reverse rotation rate: 72 207 |
Spindle stroke(mm) | 600 |
Lifting power max( KN) | 80 |
Driving force max(KN) | 60 |
Spindle output torque max(N.M) | 3435 |
Spindle hole diameter( mm) | Φ65 |
Lifting speed( m/s) | 0.43 0.78 1.35 2.08 2.95 |
Lifting capacity(single) max(KN) | 33 |
Diameter & Length of drum(m) | Φ15*90 |
Movable cylinder stroke (mm) | 400(+-10) |
Max distance from hole (mm) | 250 |
Gear oil pump model | CB-F32C-FL |
Nominal displacement( ml/r) | 32 |
Nominal pressure( MPa) | 16 |
Oil pump nominal rotation velocity(r/min) | 1800 |
Electromotor model | YB200L-4 |
Power( kw) | 26 |
Diesel engine model | K4100ZD |
Power( kw) | 36 |
Speed( r/min) | 1800 |
Weight(power unit excepted)(Kg) | 1550 |
Overall dimensions(mm) | 2400*1020*1700 |
