Product Description
Specifications
cooling fan 80*80*20mm1.CE,UL,ROHS,TUV passed
2.Air flow:25.93~38.9
3.Noise:20~31dBa
5. Water/dust proof,
cooling fan 80*80*20mm
1. Specification:
| Size(mm) | Model | Rated voltage (v) | Operating Voltage Range(v) | Rated Input Power Watt | Speed (rpm) | Max air Flow(CFM) | Max Static Pressure (Inch-H2o) | Noise Leve (dB-A) | Weight (g) |
| 80 *80 * 20 | YM1208PKS(B)1 | 12 | 7.0 to 13.8 | 2.16 | 3000 | 38.9 | 0.24 | 31 | 58 |
| YM1208PKS(B)2 | 12 | 7.0 to 13.8 | 1.56 | 2500 | 32.42 | 0.2 | 25 | 58 | |
| YM1208PKS(B)3 | 12 | 7.0 to 13.8 | 1.2 | 2000 | 25.93 | 0.16 | 20 | 58 | |
| YM2408PKS(B)1 | 24 | 14.0 to 27.6 | 3.12 | 3000 | 38.9 | 0.24 | 31 | 58 | |
| YM2408PKS(B)2 | 24 | 14.0 to 27.6 | 2.4 | 2500 | 32.42 | 0.2 | 25 | 58 | |
| YM2408PKS(B)3 | 24 | 14.0 to 27.6 | 1.68 | 2000 | 25.93 | 0.16 | 20 | 58 | |
| YM4808PKS(B)1 | 48 | 28.0 to 56.0 | 3.84 | 3000 | 38.9 | 0.24 | 31 | 58 | |
| YM4808PKS(B)2 | 48 | 28.0 to 56.0 | 3.36 | 2500 | 32.42 | 0.2 | 25 | 58 | |
| YM4808PKS(B)3 | 48 | 28.0 to 56.0 | 1.92 | 2000 | 25.93 | 0.16 | 20 | 58 |
2. General discribe:
| Frame | Plastic(UL94V-0) |
| Impeller | Plastic(UL94V-0) |
| Bearing Type | Sleeve Bearing & Bual Ball Bearing |
| Leadwire | UL1007AWG24 or Equivalent (+): Red (-0 Black |
| Motor | Impedance Protected and Reverse Polarity Protected |
3. Expexted life
1). Ball Bearing 50,000 hours(400C)
2). Sleeve Bearing 3,000hours(400C)
4. Allowable Ambient Temperature Range:
1). -100C~+700C (Operating)
2). -400C~+700C (Storage)
3). non-condensing environment
1) Higner static pressure, low noise
2) Certification: ISO9000, UL ,CE, RoHS, TUV
3) Expexted Life: 50,000 hours
4) widly used Car cooling system
More detail information, please contact with me soon. Thanks
