cpu fan4010mm
US$ 1 - 15
/ Piece
500 Pieces(Min. Order)
- SZ
- T/T
You May Like
Product Details
| Application | Other, computer case, power supply, RAM | Type | Fan | |
| Heatsink Material | Other, cooling fan | Brand Name | topfan | |
| Model Number | YM0504PFS(B)2 | Place of Origin | Guangdong, China |
Product Description
Specifications
CE,ROHS approved cpu fan4010mmExquisite&Unique design
Hign Speed, Low Noise
CE&ROHS Approved
Long Lifetime
Discription of CE,ROHS approved cpu fan4010mm:
Fan Size: 40 X 40 X 10mm
Fan Features:
| Size(mm) | Model | Rated voltage (v) | Operating Voltage Range(v) | Current amp (Amp) | Rated Input Power Watt | Speed (rpm) | Max air Flow(CFM) | Max Static Pressure (Inch-H2o) | Noise Leve (dB-A) | Weight (g) |
| 40 *40 X*10 | YM0504PFS(B)2 | 5 | 3.5 to 5.5 | 0.12 | 0.60 | 6000 | 6.33 | 0.11 | 30 | 16.00 |
Detail introduction
1. Expexted life
1). Ball Bearing 50,000 hours(400C)
2). Sleeve Bearing 30,000 hours(400C)
2. Allowable Ambient Temperature Range:
1). -100C~+700C (Operating)
2). -400C~+700C (Storage)
3). non-condensing environment
General Specification
| Model | YM0502PVS(C)2 |
| Frame | Plastic(UL94V-0) |
| Impeller | Plastic(UL94V-0) |
| Bearing Type | Sleeve Bearing & Bual Ball Bearing |
| Leadwire | UL1007AWG24 or Equivalent (+): Red (-0 Black |
| Motor | Impedance Protected and Reverse Polarity Protected |
Our Series of 40 X 40 X 10mm
| Size(mm) | Model | Rated voltage (v) | Operating Voltage Range(v) | Current amp (Amp) | Rated Input Power Watt | Speed (rpm) | Max air Flow(CFM) | Max Static Pressure (Inch-H2o) | Noise Leve (dB-A) | Weight (g) |
| 40 *40 X*10 | YM0504PFS(B)1 | 5 | 3.5 to 5.5 | 0.14 | 0.70 | 6500 | 6.80 | 0.12 | 35 | 16.00 |
| YM0504PFS(B)2 | 5 | 3.5 to 5.5 | 0.12 | 0.60 | 6000 | 6.33 | 0.11 | 30 | 16.00 | |
| YM0504PFS(B)3 | 5 | 3.5 to 5.5 | 0.09 | 0.45 | 5500 | 5.72 | 0.10 | 25 | 16.00 | |
| YM1204PFS(B)1 | 12 | 7.0 to 13.8 | 0.07 | 0.84 | 6500 | 6.80 | 0.12 | 35 | 16.00 | |
| YM1204PFS(B)2 | 12 | 7.0 to 13.8 | 0.06 | 0.72 | 6000 | 6.33 | 0.11 | 30 | 16.00 | |
| YM1204PFS(B)3 | 12 | 7.0 to 13.8 | 0.05 | 0.60 | 5500 | 5.72 | 0.10 | 25 | 16.00 | |
| YM2404PFS(B)1 | 24 | 14.0to27.6 | 0.05 | 1.20 | 6500 | 6.80 | 0.12 | 35 | 16.00 | |
| YM2404PFS(B)2 | 24 | 14.0to27.6 | 0.04 | 0.96 | 6000 | 6.33 | 0.11 | 30 | 16.00 | |
| YM2404PFS(B)3 | 24 | 14.0to27.6 | 0.03 | 0.72 | 5500 | 5.72 | 0.10 | 25 | 16.00 |
