4"-12" High-pressure hammer drill bits mining machine parts with Good Quality and Lower Price
- FOB TianJin
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
mining and well drilling blast hole 6 inch / DTH340 dth hammer bit
-
DTH360/DHD345K Bit Shank/High Air Pressure DTH Hammers With Foot Vlave
-
China High quality DTH hammer and bit for sale
-
China Good Quality/3"-12" Hign pressure DTH Hammer and bit
-
110mm / 203mm DTH Spare Parts / Water Well Drilling Bits for Borehole Drilling Hammer
-
Borehole / Water Well Drilling Tools DTH340, M50 DTH Hammer Parts
Product Details
| Place of Origin | Shandong, China | Brand Name | Miroc | |
| Model Number | High pressure dth hammers and button bits, All type | Type | Other, dth hammers and button bits, dth hammers and button bits | |
| Material | Other, Tungsten Carbide, Tungsten carbide | Use | Other, tunneling/underground constrction/quarry |
Product Description
Dth rock drill bits are in different sizes ranging from 3" to 12".
Dth rock drill bits are available in valveless model and is competent to operate in harsh conditions
dth rock drill bits have four kinds of button type
Spherical button : good wearing resistance, suited to hard ground, abrasive to very abrasive.
Parabolic button : fast penetration,suited to medium to hard rock,suitable for the mildly abrasive ground.
Conical button : fast penetration, suited for smaller diameter bits, suited for all non-abrasive ground types.
Ballistic button : fast penetration,suited to soft rock, suitable for non abrasive ground.
Applications of DTH Bit
• Underground mining
• Tunneling
• Quarry benching operations
Competitive Advantage
• High grade tungsten carbide inserts
• Bit bodies manufactured from high grade steel and processed using state-of-the-art CNC machinery and heat treatment
Product Code and Brief Description | Flushing Holes | Diameter (mm) | Weight (kg) | Gauge Buttons ( No.x mm) | Front Buttons ( No. x mm) | DTH Hammer |
DTH65PQ | 1 | 68 - 72 | 1.5 | 4 x12 | 3 x 12 | DTH65 |
DTH75PQ | 3 | 75 - 77 | 2.4 | 5 x 12 | 3 x 12 | DTH70 |
DTH76PQ | 2 | 76 - 78 | 2.5 | 5 x 12 | 3 x 12 | DTH76 |
DTH76-78 | 2 | 78 - 82 | 2.6 | 5 x 12 | 3 x 12 | DTH76 |
DTH80PQ | 3 | 82 - 84 | 3 | 5 x 12 | 6 x 12 | DTH80, DTH80X |
DTH90A | 3 | 90 - 95 | 3.6 | 6 x 14 | 4 x 12 | DTH80, DTH80X |
DTH80XD-90 | 3 | 90 - 95 | 3.4 | 6 x 12 | 4 x 12 | DTH80XD |
DTH80-II-80 | 3 | 80 - 82 | 3 | 5 x 12 | 4 x 12 | DTH80-II |
DTH90B | 3 | 90 - 95 | 3.8 | 6 x 14 | 4 x 12 | DTH90, DTH90-I |
DTH90T1 | 2 | 90 - 95 | 3.6 | 6 x 14 | 1x12,3x12 (Spherical) | DTH90, DTH90-I |
DTH90T2 | 2 | 90 - 95 | 3.8 | 6 x 14 (Spherical) | 4 x 12 (Spherical) | DTH90, DTH90-I |
DTH90T3J | 3 | 90 - 95 | 3.6 | 6 x 14 (Ballistic) | 4 x 12 (Ballistic) | DTH90, DTH90-I |
