USB Microscope

Place of Origin	Guangdong, China		Brand Name	OITez
Model Number	DP-M01 M2020U		Theory	Video Microscope
Drawtube	Binocular

Specifications

- 2.0 Mega image sensor
- USB-port connet with PC
- Capture photo or video
- Portable and easy to carry

The Microscope is a fully functional magnification device which can easily be operated by plugging directly into your computer enabling you to magnify objects up to 10X-50X & 200x. Enhanced with adjustable light control wheel with 8 white LED lights and a 2MP PC camera, the Microscope can capture high quality images and videos (AVI).

The full package includes a user friendly image processing software (Amcap), a lens cover and a detachable stand. Additionally, this high end digital microscope requires no batteries, receiving its power directly from the computer USB power. The Microscope is compact and innovative design, as well as its easy accessibility option, make it a perfect candidate for classroom projects for scientific teaching and research.

Other uses for the Microscope include:

-Classroom teaching aid
-Scientific and laboratory research tool including dissection and examination of specimen
-Medical analysis such as dermatological examinations, etc
-Reading Aid
-Industrial Inspection
-Computer Parts inspection
-Textile Inspection
-Jewelry Inspection
-Collections/Coin Inspection
-Printing Inspection





Before Magnifying



Magnifications: 10-50X



Magnifications: 200X



Specifications:

Image Sensor	2.0Mega Pixels
Video Capture Resolution	1600x1200,1280x960,800x600,640x480,352X288,320x240, 176x144,160x120
Still Image Capture Resolution	3200x2400, 2560x2048, 2304x1728, 1600x1200(Interpolation), 1280x1024,1280x960,1024x768,800x600,640x480
Color	24bit RGB
Lens	Microscope Lens 10X-50X,200X
Focus Range	Manual Focus From 10mm to 500mm
Flicker Frequency	50Hz/60Hz
Frame Rate	30fps@VGA
Magnification Rate	10X-50X,200X
Shutter Speed	1 sec. To 1/1000sec.
Video Format	AVI format
White Balance	Auto
Exposure	Auto
Light Source	8 LED White Lights (High /Low )
PC Interface	USB2.0
Operation System	Windows XP/Vista/Win7
Driver Installation OSD Language	Multi-language
Power Supply	5V DC from USB Port
Size	142mm(L) x38mm(D)



Accessories:

A1-Alloy Stand
Safety Cover
User Guide
CD ROM Driver (Amcap)
Gift Box

Packing:

Unit: 25x 16 x 6cm (L x W x H)
Weight: Including Metal Stand 385g
10pcs/ctn.
Dimension: 33.8x 32.1x 27.8cm (L x W x H)
Gross weight: 5kg
