Home > Products > Single phase energy meter > Single Phase Anti-tampering Electronic Energy Meter
Single Phase Anti-tampering Electronic Energy Meter
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | YTL, YTL(electronic energy meter) | |
| Model Number | DDS-1Y, DDS-1Y(electronic energy meter) | Display Type | Analog and Digital | |
| Phase | Single Phase | Measuring Energy Range | 5/60A, 10(40)A 5(100)A | |
| Accuracy Class | 1.0 2.0, 1.0, 2.0 | Output Voltage | 220V,230V,240V, 110V 220V 230V 240V | |
| Operating Temperature | -30~+55, -30~+55 | Dimensions | 215*106*60MM, 215*106*60mm |
Product Description
Specifications
This is single phase anti tamperig electronic energy meter with long and transparent cover.electricity meterSingle Phase Anti-tampering Electronic Energy Meter
As a professional manufacturer, YTL designs and produces watt-hour meter which are cost-efficient and ideal for the use in solutions for AMR/AMI at residential as well as industrial applications.
YTL is devoted to develop and design all types of watt-hour meter, concentrators and solution applications. With a combined design of the special accessories, we have successfully developed series of competitive products of small size, multifunction, low power consumption and excellent performance. We offer a one-to-one service to our partners. With annually over 68 projects that are successfully finished and holding over 200 patents of design rights, we are also advanced in the technology and patents of current sampling.
1.Product Details | ||
Product Name | Single Phase Anti-tampering Electronic Energy Meter | |
Installation type | Suspension type | |
Module No. | DDSO-L02 | |
Brand | YTL | |
Rated Current | 10(40)A 5(100)A | |
Reference Voltage | 110V 220V 230V 240V | |
Frequence | 50-60Hz | |
Display Mode | LCD | |
Accuracy | 1.0 | |
Impulse Constant | 800/1000imp/kWh | |
Start Current | 0.004Ib | |
Connection Mode | Direct mode | |
Communication& Protocol | / | |
Power Consumption | IEC standard or customized | |
Material of meter case | PC | |
Size | 215*106*60MM | |
Certificate | CE | |
Standard | IEC62053-11 | |
2.Functions and characteristic | ||
A. LCD display with anti tampering | ||
B. BS connection | ||
C. | ||
… | ||
3.Outer and mount dimension: | ||
 | ||
4.Wiring diagram: | ||
| | ||
5.Transaction Information | ||
MOQ | 500pcs | |
Sea Port | Shanghai | |
Payment Terms | TT prepayment | |
Supply Ability | 50,000pcs per month | |
Delivery time | 50,000pcs of energy meter per month | |
Normal Package | white or colorful box | |
