Lighting appliances mechanical shock tester
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Sunho | |
| Model Number | SH3328 | Power | Electronic | |
| Usage | Other |
Product Description
It is designed according to the chapter 4.11.6 in IEC60598, during the test process, it need use together with the power load, to carry on the power on test, after finished the mechanism test times, can switch to do the pressure drop test.
Technical parameters:
l Power supply:AC220V±10% 50Hz
l Gas source: 6~8kg/cm2
Power on time:0~99.9s (min) adjustable
l Test on and off mode: With intelligent control system, can separate to control the load connected, breaking off control.
l Intelligent discriminant function: When the test sample bonding, it occurs continuously turned on or off, then it reached to set number, it will alarmed.
Test cycle time:0~99s, adjustable
Counter:0~9999. Can be preset
Test station:1
Contact pressure measurement test current range:AC 1~100A;
Pressure drop measurement range:0~199.9±1mv
Based on the real use speed to operate 100 times, the voltage, current, load power factor will not changed.
