Pulse current Tester
You May Like
Product Details
| Place of Origin | China | Brand Name | Sunho | |
| Model Number | SH3101F | Power | Electronic | |
| Usage | Other, Safety tester |
Product Description
It is designed according to the relevant standard requirements of IEC61347.
Technical parameters:
1. Power supply is AC220V 50HZ
2. The capacity energy storage of the Capacitor
3. Charging power supply, Voltage is 0~60V
4. Power is 1000VA, it is the DC Switching Power Supply
5. Voltage accuracy is ±3%.
6. Charging time is 0.5s~10s, the accuracy is ±0.1s
7. Discharge time is 0.5s ~ 10s, accuracy is ± 0.1s
8. Charging Number is adjustable from 1-999
9. The charging and discharge loop resistance is ≤ 1.2Ω
10. Display mode: LCD display the operation interface
11.Output test wire 0.5mm2 hightemperature copper wire, and the length of it is 1m.
12. With the Safety switch testing box
