spout pouch making machine

FOB Price

Negotiable / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Machine Type	Bag Forming Machine
Place of Origin	Jiangsu, China	Brand Name	Shengning
Voltage	280v	Power(W)	8kw
Dimension(LWH)	5200x2000x1700mm	Weight	2500kg
Warranty	12 month	After-sales Service Provided	Engineers available to service machinery overseas

This machine is used to weld stand up spout pouch. It is suitable for packaging juice, jelly, milk ,liquid pets food .

1.Usage
This machine is used to weld stand up spout pouch. It is suitable for packaging juices, jelly, milk,Liquid pets food and Dish washing liquid.

2. Main Technique Features

l Spout fitting and sealing with self-standing pouches and penguin style pouches

l Servo motor drive

l PID temperature control

l Clear display and easy operation

l Plastic pouches lined in the special holding channel for later feeding

l Trouble alarm display and shooting

Spare and accessory parts:4 gear cases ,3 slicers, SMC, couplings.

3. MAIN TECHNICAL SPECIFCATIONS

Pouch pattern	Stand up Pouch, Three Side Seal Pouch, Center Seal Pouch, Side Gusset Pouch, Spout Pouch
Color of machine	White
Pouch size	Width (60~122)mm,Height(60~230)mm Special specifications can be tailor-made
Control mode	PLC+Mechanical transmission
Hot-sealing	Six groups (12pcs)
Compressed air	0.5Mpa. 10L/min
Control system	PLC+Mechanical transmission
Power	380V 50HZ( Special specifications can be tailor-made )
Main motor power	8Kw,Warm-up(20Kw)
Efficiency	1~80Pcs/min
Accuracy	±1mm
Weight	2500Kg
Pouch mode	Single or double group
Dimension of the machine	5200x2000x1700mm
