IP65 Rear Panel Mounting Silicone Keyboard With PS/2 Interface
- shenzhen
- T/T Credit Card
You May Like
-
IP68 Dynamic Sealed & Ruggedized Silicone Industrial Keyboard With Touch &rubber Touchpad
-
Custom IP65 Dynamic Sealed & Ruggedized Military Silicone Rubber Hygienic Keyboard
-
IP68 Medical Silicone Keyboard With Numeric Keypad and Function Keys
-
Silicone Rubber Keyboard With Touchpad,function Keys and Desktop
-
Excellent Tactile Feeling Quality Rubber Keyboard in Factory Price
-
Excellent Tactile Feeling Silicon Waterproof Keyboard in Factory Price
Product Details
| Products Status | Stock | Application | Other, Industrial | |
| Type | Wired | Style | Slim, Standard, Other | |
| Interface Type | PS/2, USB | Brand Name | IKB-MKB | |
| Model Number | K-TEK-M270-FN-OEM | Place of Origin | Guangdong, China |
Product Description
IP65 rear panel mounting silicone keyboard with PS/2 interface
Description:
1. 83 keys IP65 dynamic sealed & ruggedized industrial silicone rubber Hygienic keyboard with industrial PCB included
2. 12 function keys and industrial PCB with carbon-on-gold key switch technology with long stroke (1.50mm) with extremely
good tactile feeling for fast and accurate data input without any noise.
3. with durable coating & anti-microbial keyboard surface withstand to most chemicals and liquids under harsh
environment.
4. Clean key for easy cleaning via lock/disable whole keyboard without needing to take keyboard from PC
5. Panel mounted version, adjustable industrial backlight optional. Military level optional
Special Features:
1. Keyboard with NVIS-compliant red adjustable backlighting optional, while NVIS backlighting makes this keyboard ideal for
aviation or vehicle applications where night vision goggles are necessary.
2. Keyboard provides full-size versatility in a rugged, compact design, rugged construction for reliable functionality
3. The keyboard lacks the crevices found between the keys of a regular keyboard, which is protected against dust, dirt,
grease and corrosive liquids to NEMA 4X, which means it can withstand directed hose water, disinfectants, environmental
contaminants and heavy industrial use.
4. Special durable-coating for excellent mechanical and chemical resistance
5. Clean key -Prevents data from being sent while the keyboard is wiped down, allowing user to clean at any interval with
minimal downtime-User is notified of ‘lock down mode’ by brightly lit CLEAN KEY
6. With firm tactile key feel, key travel 1.5mm key travel.
7. Ease of customizing with multiple languages, to accommodate foreign or custom variants.
8. PS/2, USB connection cables that plug directly into computer like keyboard operations.
9. Enclosure: industrial silicone, stand alone back plate optional
Applications:
This keyboard is ideal for use in environments ranging from manufacturing to material handling to medical settings. Its
numeric pad allows for easy data entry.
A: MEDICAL: lab, hospital, clinic, dental, such as carts, diagnostic equipments, operation rooms, dialysis centers etc;
B: MATERIAL HANDLING: mobile keyboard, data entry, assembly line etc
C: MILITARY: Army, Navy, Air force
D: INDUSTRIAL: Industrial automation, pharmaceutical, oil and gas, food and beverage, clean or dirty manufacturing
environments, warehouses
E: OTHER INDUSTRIES
Specification
MECHANICAL DATA | |
Key | 83 keys |
Key top style | Protuberant rectangular keys with tactile feeling. |
Key Size | 12.0mm X 13.0mm for normal keys, |
Key travel | 1.5mm |
Switch life | more than 10 million of operations |
G.W. | 1.0KGs |
Dimensions: | 270.0mm x 113.0mm(L x W ) |
ELECTRICAL DATA | |
Supply Voltage | +5V DC +/-5% |
Current Rating | 20mA (non-backlight), 140mA (with backlight on) |
EMC Standard: | It is compliance with the council IEC 61000-4-2:2008;IEC 61000-4-3:2006+AI:2007+A2:2010;IEC 61000-4-4:2004 |
EMI: | EN 50081-1 |
Immunity: | EN 50082-1 |
Lifespan | > 3 years |
Switch Contact Material: | Carbon-on-Gold key switch technology with gold PCB. |
Interface: | PS2, USB available. |
OS: | All windows, Linux, Unix, Mac OSX |
ENVIRONMENTAL ADAPTABILITY | |
Operating temperature | -20oC to +60oC(industrial level);-40oC to +85oC(military level) |
Storage temperature | -30oC to +70oC(industrial level);-55oC to +150oC(military level) |
Humidity | 100% |
Atmospheric pressure | 60-106Kpa |
Shock | 3x11 ms pulses of 50g on each of 3 axes |
Vibration | POWER SPECTRAL DENSITY: 0.04g/Hz, FREQUENCY RANGE: 20Hz - 2kHz, DURATION OF TEST PER AXIS: 3 hours |
Printed Circuit Board | 94 VOSILICONE OVERLAY: 94 HBINTERFACE CABLE: 94 V |
RELIABILITY | |
Certification | RoHS Compliant, CE and FCC, ESD |
Protection Level | IP65(front panel);NEMA 6P |
Key Lifespan | >10 million actuations |
MTBF | >50000H |
MTTR | <30min |
