Home > Products > LED Deco Lighting > Outdoor DMX LED Vision Tube lights SLVT5010
Outdoor DMX LED Vision Tube lights SLVT5010
- 1 Piece / Pieces per Month
- Shengzhen
- T/T
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Summitlite | |
| Model Number | SLVT5010 |
Product Description
Specifications
LED Vision Tube lights SLVT5010- Summitlite can support two types of DMX function solution.1.buttom outlet cable
2.Aside
Summitltie LED Vision Tube Series:
Item Name SUmmitlite LED vision Tube
Item code: SLVT5010; SLVT5005
Keywords: LED vision tube, digital vision tube.
Product introductions:
SUmmitlite LED Vision Tube (Abbrev, SLVT series) is an advanced tube design and the latest version of the LED Tube from Summitlite tube system. SLVT is a video grade tube and can be set to 8, 16, 32 pixel resolutions per tube.
SLVT series uses the very latest in high quality tri-color (RGB) LEDs to provide high luminosity even and consistent colors. SLVT can be directly controlled by DMX-512 or our PC Video Control System.
It is similar like Summitlite LED Tube DMX Versionl the DMX writing via SLDC1020. But for video effect through another two controllers SLVT5010C main controller + scanner SLVT5010S whcih is including a receiving card.
100CM and 50 cm SLVT is available !
Technical Specifications:
| Summitlite Vision Tube series | ||||
| SLVT5010 | ||||
| Item No | SLVT5010-220V | SLVT5010-120V | ||
| LED Color | RGB | |||
| Luminance | 60 lm | |||
| Tube section(mm) | Φ50 | |||
| Tube cover | Milky white PC with anti UV | |||
| Length | 1000mm | |||
| Qty. of tube | 144PCS DIP HI-Bright LED | |||
| Operating Temperature | -20 to 40 | |||
| Operating Humidity | 0 to 95 | |||
| Protection rate | IP65 | |||
| Connector | 5-pin connector | |||
| DMX channels | 3,6,12,24,48 | |||
| Control sytems | SLVT5010S (scanner) + Video controller SLVT5010C +PC | |||
| Functions | Video Play ( Via software | |||
| Input Voltage | 200-240V | 100-120V | ||
| Input Current | 1.4A | |||
| Max Power | 16.8W | |||
| Dimensions | 1000LX50WX94Hmm | |||
| Net Weight | 1.8KG | |||
| Light output | ||||
| Color | Red | Green | Blue | White |
| Total output(lumen) | 10.5 | 42.3 | 14.5 | 63.9 |
| Power (Watt) | 2.4 | 4.8 | 4.8 | 12.0 |
| Efficiency(Lm/W) | 4.4 | 8.8 | 3.0 | 5.3 |
