10.4inch IPS High Brightness Screen Lcd Lvds Interface for Outdoor Use
Negotiable
/ Piece
1 Piece(Min. Order)
- Shenzhen
- T/T Credit Card
You May Like
-
10.4inch 1000nits High Brightness Screen Display Support Lvds Interface
-
10.2inch High Brightness Screen Panel With Lvds Interface
-
10.1inch 1000nits 1024*600 RGB Outdoor Display Panel Capacitive Touch With CTP
-
10.1inch 1024*600 1000nits Outdoor Display Module With RGB Interface
-
8inch 500nits 1024*600 Lvds Interface High Brightness Panel Capacitive Touch Display With CTP
-
8inch 1000nits 1024*600 Outdoor Lcd Module Display With Lvds Interface
Product Details
| Place of Origin | Guangdong, China | Brand Name | Wilcon | |
| Model Number | SW106N-SV1 | Type | TFT |
Product Description
10.2 inch IPS high brightness screen lcd lvds interface for outdoor use
Specification:
| Items | Parameters | |
| Basic information | Model | SW106N-SV1 |
| Size | 10.6 | |
| Work Temperature | 0-50℃ | |
| Storage Temperature | -40-70℃ | |
| Environment Humidity | <90%RH | |
| Structure Characters | Display Ratio | 15:9 |
| Pixel Pitch | 0.060*0.180 | |
| Resolution | 1280*768 | |
| Display Area | 230.4*138.24 | |
| Active Area | 233.4*141.3 | |
| Dimension | 248.8*155.8*6.5 | |
| Hole Support | Opening hole in side or front edge | |
| Backlight Model | Direct-in type | |
| Display Model | IPS,Normally black display, Transmissive | |
| Brightness | 1000cd/m2 | |
| Brightness Mangagement | Beam controller (automatic adjustment)/manual adjustment | |
| Contrast Ratio | 1000:1 | |
| Display Color | 262K | |
| Response Time | 8ms | |
| Viewing Angle | IPS | |
| Port Type | LVDS | |
| Cooling Way | Cooling System | Military grade aluminum heat dissipation board |
| Packing Material | Carton/Wooden Box | |
| Gross Weight | / | |
| Warranty Time | 1 year(Except human factors) | |
High brightness lcd compare with the normal brightness lcd
