Polyolefine heat shrinkable thin wall tubing
USD $0.03 - $10
/ Roll
1 Roll(Min.Order)
- 0 per Month
- Dalian
You May Like
Product Details
| Place of Origin | China | Brand Name | UPM heat shrink | |
| Model Number | S2(n) | Type | Insulation Sleeving | |
| Material | PE | Application | Low Voltage | |
| Rated Voltage | 600V |
Product Description
Specifications
Flame retardant,Irradiated polyolefin heat shrink tubing of many colors,both insualtion and sealing. Shrink ratio: 2:1,3:1
| Brand | UPM heat shrink | |
| Property | test method | typical data |
| Tensile strength Mpa | ASTM D 2671 | ≥10.4 |
| Ultimate elongation | ASTM D 2671 | >350% |
| Longitudinal shrink ratio | ASTM D 2671 | ≤±5 |
| Flammability | UL224 | VW-1 |
| UL file No. | UL224 | E236437 |
| Heat shock | ASTM D 2671 | 200°C,no drop/no flow |
| Voltage withstand | / | 600V |
| Dielectric strength KV/mm | ASTM D 2671 | >15 |
| Volume resistance Ω.cm | UL224 | >1014 |
| Copper stability | UL224 | pass |
| Copper corrosion | UL224 | No corrosion |
| Operating temperature | / | -40°C~+125°C |
| Shrink ratio | / | 2:1, 3:1 |
| Water absorption | ASTM D 570 | <0.5% |
· Shrink ratio 2:1 and 3:1 available, providing easy installation even if there are large diameter differences
· Excellent flexibility, does not easily wrinkle
· Ideal for electronic insulation and protection, strain relief and wire bundling
· Common applications include electronic systems of subway, air craft, submarine and other control room facilities and environments
· RoHS compliant halogen free, environmentally friendly
· Flame retardant meets the UL 224 VW-1 standard
