22V DC Small Water Pump Motor Home

Specifications

Specifications

DC Small Water Pump Motor in China

1. Ideal For Water Pump

2. 27.7*37.8mm Case

3. REACH Compliant

4.4700rpm,0.05A free-run

22V DC Small Water Pump Motor in China( RS-385PHV-12222R )

DIMENSION DRAWING:

1.MEASURING CONDITIONS
        1.1.Rated voltage:                     22   V DC
        1.2.Motor Position:                    To be measured with motor horizontally held.
        1.3.Environmental temperature:25±10°C.
        1.4.Environmental humidity:65%±20%RH.
2.ELECTRICAL CHARACTERISTICS(At initial stage after 30 seconds run-in):
        2.1.At No load
             2.1.1.Speed:                      4700 ±10% rpm
             2.1.2.Current:                    0.05   A(max  0.10 A)
        2.2.At Max Efficiency
             2.2.1.Torque:                     6.7mNm

             2.2.2.Speed:                      3778 ±10% rpm
             2.2.3.Current:                    0.21    A
        2.3.At Stall
             2.3.1.Torque:                     34mNm
             2.3.2.Current:                    0.84A

        2.4.Direction of Rotation:             CCW  (Counter-Clockwise when viewing from the output shaft end with positive voltage applied to positive terminal.

3.MECHANICAL CHARACTERISTICS

        3.1.Dimension drawing:               See<OUTLINE>.
        3.2.End Play:0.05~0.55mm                 MAX.
        3.3.Class H magnet wire.  Stainless steel shaft (304)
        3.4.Operating Temperature:                -10°C ~ +60°C.

PRODUCTION FLOW:
