MFR20 Coal Burner For Asphalt Plant

FOB Price

US$ 10,000 - 20,000 / Set

1 Set(Min. Order)

Port Qingdao Shanghai Tianjin
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Henan, China		Brand Name	ZOOMLINE
Condition	New		After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

MFR 20 Coal Burner

Our MFR series coal burner is the latest generation heating device on base the advantages of other models. MFR20 coal burner features:

1.MFR20 coal burners own exclusive use of rotary combustion burners to solve the traditional burn which is easy to slag-bonding and cannot burn completely etc.

2. High flame temperature makes the coal burners more energy saving and burning more completely.

3. MFR20 coal burners can continues to produce.

4. MFR20 coal burners have simple and easy ignite way. They can be ignited by both manual and automatic way.

5. MFR20 coal burner costs low.

Main configuration of MFR20 coal burner

MFR20 coal burner
Coal consumption: 180-280kg/h		Flame diameter: 0.4m;Flame length:0.6-1m
Working noisy ≤85dB(distance about 1m)		Total power:21.75kw
Power of reducer:1.5kw		Power of rotate motor:1.5kw
Ignition Fuel System
Oil pump: CB-B10		Overflow valve: Y-25
Pressure gage: 0-4MPa		Motor power: 0.75KW
Fuel oil for ignition: 0# diesel
Air system
Blower		Motor power: 5.5KW
Coal powder grinding machine
Model: MFJ20	capacity:180-280kg/h
Feed aggregate size: ≤25mm	Discharging size: R90≤20% (0.09mm residual volume mesh)
Main motor power: 11KW	Main motor speed: 1470rpm
Adjustable-speed motor power: 1.5KW	Adjustable-speed motor speed adjustable range: 250-160
Speed of main shaft: 1700rpm	Hopper volume: 0.2m3
Dusting distance: 7-12m	Speed of screw conveyor: 8.3-80rpm

MFR20 coal burner equipped with MFR250 main machine, MFJ20 coal machine, RYDH diesel igniter and PD20 cabinet. The other accessories of MFR20 coal burner could be optional according to the customers’ requirements.
