Explosion Proof Potentiometer for Panel Mounting
US$ 120 - 130
/ Piece
1 Piece(Min. Order)
- Shanghai
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Explosion Proof (flash) Buzzer for Panel Mounting
-
IECEx&ATEX Rail Type & Back Type Explosion-proof Ammeter Voltmeter MA-meter
-
Hot Sale IECEx&ATEX Certified Explosion-proof Signal Lamp With Push Button
-
IECEx ATEX Certified Explosion Proof Potentiometer Component for Board Front Mounting and Board Back Type Most Popular
-
Explosion Proof (flash) Buzzer for Board Back Type Mounting
-
IECEX Certified Full Plastic Explosion Proof Position Switch
Product Details
| Place of Origin | Zhejiang, China | Brand Name | CZ | |
| Model Number | CZ0203 | Type | Rotary Potentiometer | |
| Technology | Other, Plastic | Resistance | 100-200M | |
| Resistance Tolerance | 1% | Rated Power | 0.1W | |
| Max. Operating Voltage | 200V DC | Operating Temperature | -40℃ to 50℃ |
Product Description
Desceiption:
Main Technical data:
| Ex mark | Ex de IIC T6 Gb Ex tb IIIC T80 ℃ Gb |
| Intended use | Can be used in zone 1, zone 2, zone 21 and zone 22 |
| Ambient temperature | -40 ℃ ≤Ta ≤ 50 ℃ |
| Degree of protection | IP66 |
| Rated voltage | 200V DC or power rating, whichever is smaller |
| Rated power | 0.1W |
| Scale | 0-100% |
| Cable entry outer diameter | Φ5.5-13mm |
Order Specification:
Outline dimensions:
