ML22 Double Corrugated Straw Making Machine

FOB Price

Negotiable / Set

1 Set(Min. Order)

Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	Marrow
Model Number	ML22	Voltage	220V or 380V
Power(W)	1.5KW	Weight	1100kgs
Certification	ISO, CE	Warranty	one year
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

ML22 Double Corrugated straw making machine,it can make two corrugated parts ( flexible parts) on the straw.

ML22 Z-Shape Flexible Straw Auto Making Machine

DESCRIPTION

Model ML22 Z-shape flexible straw auto making machine is a special machine of making Z-shape flexible drinking straws. The straight straws supplied in the hopper at the top of machine ,passes through 12 sets of conveyor and 12 sets of double-screw needle and 1 sets of double-screw shaping wheel, delivered to output conveyor automatically.

TECHNICAL FE ATURE

1. High efficiency and high production rate,

2. Automatic product counting,

3. Automatic stop in the event of straw jamming,

4. Hopper in stainless steel is set at conveyor, one man can operate two machines,

5. Special repairing safety button ,

SPECIFICATIONS

Model		ML22-4	ML22-5	ML22-6
Capability		200250pcs/min
Main motor		1.5kW (VFD)
Specifications of straw	Diameter	φ3.8mm	φ4.8mm		φ5.8mm
	Length of straight straw	155245mm	190245 mm		190245 mm
	Length of flexible straw	140235 mm	175235 mm		175235 mm
	Thickness of straw	0.18±0.02 mm	0.16±0.02 mm		0.16±0.02 mm
	Top section length	30 mm
	Length of the first flexible part	810 mm(10 teeth)
	Length of the second flexible part	56(6 teeth)
	Machine weight	1100KG
	Dimension	1200mm(W)×1800mm (L)
Other specifications are customizable
