ML28 Telescope Straw Making Machine

FOB Price

Negotiable / Set

1 Set(Min. Order)

Port SHANGHAI/NANJING
Payment TermsT/T

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Jiangsu, China	Brand Name	Marrow
Model Number	ML28	Voltage	380V
Power(W)	1.5kw	Dimension(LWH)	100300150
Weight	600kg	Certification	CE/ISO9001
Warranty	1 Year	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

ML28 TELESCOPE STRAIGHT STRAW MAKING MACHINE

DESCRIPTION

Model ML28 Telescope straight straw auto making machine is a special machine of making telescope drinking straws. They are consist of 3 sets of machines,One is expanding for inner straw, others two sets machine is shrinking for outside straw. The straight straws supplied in the hopper at the top of machine ,passes through 12 sets of conveyor and 12 sets of heating die, delivered to output conveyor automatically.

TECHNICAL FEATURE

1. High efficiency and high production rate,

2. Automatic product counting,

3. Expanding and shrinking of telescope straw can be adjusted,

4. Hopper in stainless steel is set at conveyor, one man can operate two machines,

SPECIFICATIONS

Model		ML28-4.5	ML28-5.5	ML28-5.5
Function		Inner expanding	Outside shrinking	Outside shrinking
Capability		200250pcs/min
Main motor		0.75kW (VFD)
Power of heater die		1.5kW
Specifications of straw	Diameter of straw	Φ4.5mm	Φ5.5mm	Φ5.5mm
	Length of straight straw	90130	80120	80120
	Thickness of straw	0.190.25 mm

Contact Us

Nanjing Marrow Machinery Manufacture Co., Ltd.: Contact nameCrystal Hu
Chat Now; Phone0086-25-52374600; AddressNo.231 Lantian Road, Nanjing, Jiangsu
