Zhengzhou STA clamps and straps for Mosi2 heating element

FOB Price

US$ 1 - 8 / Piece

10 Pieces(Min. Order)

Port Qingdao Shanghai
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Other, Furnace heater
Power Source	Electric	Place of Origin	Henan, China
Brand Name	STA	Model Number	STA-MS
Dimension(LWH)	customizable	Weight	according to size
Voltage	Rated voltage	Power(W)	Adjustable
Certification	ISO9001:2008	Warranty	1 YEAR
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Zhengzhou STA clamps and straps for Mosi2 heating element

MoSi₂ Heating Element has the ability to withstand oxidation at high temperatures. This is due to the formation of a thin and adhesive protective layer of quartz glass (SiO₂) on the surface. When the element temperature over 1700℃, SiO₂ protective layer which melting point is 1710℃ was fused, and because of the surface tension, it fused into drops, which is useless. However, when element continue working in oxidizing atmospheres, the SiO₂ protective layer is spontaneously rebuilt.

Notice: It is no good to use Molybdenum Disilicide Heating Element for Long-term within a range of 400-700℃, otherwise the element will be powdered by the strong low temperature oxidation.

Physical Properties

Bulk Density	Bending Strength	Hardness	Water Absorption	Heated Elongation	Fracture Toughness	Compression Strength
≥5.8g/cm³	350MPa	9.9GPa	≤0.2%	≤4%	4.5MPa.m^1/2	650MPa

The influence of operation temperature on the heater surface in a different atmosphere

Atmosphere	1700 Type	1800 Type
Air	1700	1800
N2	1600	1700
He	1600	1700
-80°C Dry H₂	1150	1150
-20°C Wet H₂	1450	1450
10%CO₂, 50%CO, 15%H₂	1600	1700
40%CO₂, 20%CO	1400	1450
Cracked and Partially Burnt Ammnia	1400	1450

Straps and Clamps for Mosi2 heating element:
