STA Strong functional molybdenum heating elements forheating treatment

     STA Strong functional molybdenum heating elements forheating treatment

1.MoSi2 electric heating elements is a kind of resistance heating element made from Molybdenum Disilicide. It can be exerted under the high temperature of the oxidated atmosphere. MoSi2 elements have the unique function of high temperature anti-oxidation. Under the oxidated atmosphere, the maximum temperature of MoSi2 elements is 1800°C. It can be made into various types, including U-type, W-type, right-angle as well as circular type.

 The general temperature of MoSi2 heating rods is from 1300°C to 1800°C, which is universally applied to the field of  metallurgy, glass, ceramics, magnetic matrials, refractory materials, crystals, electron devices and kiln etc. It is the ideal heating element of high temperature anealing.

2.Technical Data of MoSi2 electric heating elements:

3.The influence of operation temperature on the heater surface in a different atmosphere

4. MoSi2 heating elements physics and chemistry characters:

STA MoSi2 elements are made to industry standard established resistance values, dimensions and geometries, and therefore are interchangeable with other manufacturers of molybdenum disilicide elements.

STA MoSi2 elements are graded in two maximum temperature ranges of 1700°C (3090°F) and 1800°C (3270°F). Elements are available in many shapes and forms (see examples shown below). Specifically, we offer the following MoSi2 styles: “U-shaped” (most common), “W-shaped”, and “Straight-shaped”, with or without right angle or oblique angle bends.

Examples of typical MoSi2 element configurations.

d=6mm, c=12mm, Le=200mm, Lu=180mm, a=30mm

Please specify as: dia6/12x200x180x30mm (dia d/cxLexLuxa mm)

d = the diameter of hot zone

c = the diameter of cold zone

Le = the length of hot zone

Lu = the length of cold zone

MoSi2 Element Accessories

a full range of accessories for mounting and wiring MoSi2 elements including:

• support clamps
• braided aluminum straps
• power buss bars
