Home > Products > skid steer loader > W720T Skid steer loader
W720T Skid steer loader
Negotiable
/ Set
1 Set(Min. Order)
- QINGDAO
- T/T
You May Like
Product Details
| Condition | New | Brand Name | HUACHENG-LIONKIN | |
| Model Number | W720T | Place of Origin | Shandong, China | |
| Type | Skid Steer Loader | Moving Type | Wheel Loader | |
| Dimension(Long * Breadth * High) | 1.32X1.75X0.92m | Rated Load | 200Kg | |
| Certification | ISO CE EPA | Warranty | ONE YEAR | |
| After-sales Service Provided | No overseas service provided |
Product Description
Specifications
OUR PRODUCTS IS WITH CE ANS EPA CERTIFICATION
| Mini Skid Steer Loader | |
| Type | W720T |
| Engine brand | KOHLER |
| Pump brand | ZANEDA |
| Rated power | 26HP |
| Performance parameters | |
| Operating weight | 860kg |
| Rated load | 200kg |
| Maximum load | 450kg |
| Drive system | |
| Transmission form | motor drive |
| Tire/Track | crawler 280 |
| Driving wheel | - |
| Maximum walking speed | 10km/h |
| Hydraulic system | |
| Operation mode | hydraulic |
| System pressure | 17MPa |
| Output standard flow rate | 25L/min |
| The maximum output flow | NA |
| Electrical system | |
| Voltage | DC12V |
| Gas volume | |
| Hydraulic tankL | 27L |
| Fuel tank | 21L |
| Outline dimensions | |
| Total high | 1320mm |
| Total length(without bucket) | 1750mm |
| Total width | 920mm |
| Operation parameters(with bucket) | |
| Operating height | 2160mm |
| To bucket pin height | 1810mm |
| Level bucket bottom height | 1730mm |
| With standard bucket length | 2205mm |
| The maximum height on the flip angle | 25º |
| The maximum height of the discharging angle | 30º |
| Discharge height | 1412mm |
| Discharge distance | 530mm |
| Wheelbase | 652mm |
| Tread | 640mm |
| Ground clearance | 140mm |
| Angle of departure | 15º |
| Bucket width | 820mm |
| Bucket capacity | 0.12m³ |
