Home > Products > RF Cable Assembly(Jumper Cable) > RG214 Cable Assembly with 7/16 Male Crimp Connectors
RG214 Cable Assembly with 7/16 Male Crimp Connectors
US$ 3.88 - 4.34
/ Piece
100 Pieces(Min. Order)
- Shanghai
- T/T Credit Card PayPal
You May Like
-
RG214 Cable Assembly with N Male Crimp Connectors
-
RG214 Cable Assembly with N Male Crimp to N Female Crimp Connectors
-
RG214 coaxial cable assemlby with N connector
-
RG214 Cable Assembly with N Male Clamp to N Male Right Angle Clamp Connectors
-
RG214 Cable Assembly N connector plug clamp type
-
RG142 Cable Assembly with N Male Crimp to BNC Male Crimp Connectors
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Four Star | |
| Model Number | 7/16-C-J214/7/16-C-J214-200 | Type | Coaxial | |
| Number of Conductors | 1 |
Product Description
Product Description
| 200mm RG214 Cable Assembly with 7/16 Male Crimp Connectors On Both Ends | ||
| Model No. | 7/16-C-J214/7/16-C-J214-200 | |
| Connector Type | A Side: 7/16 Connector Male Crimp for RG214 Cable | |
| B Side: 7/16 Connector Male Crimp for RG214 Cable | ||
| Cable Type(Name) | RG214 Cable | |
| Cable Length | 500mm (Customized Length Available) | |
| Connector Interface | IEC 60169-4 | |
| Typical Frequency Range | DC-3GHz | |
| VSWR | ≤1.30@DC-3GHz | |
| Intermodulation 3rd (PIM3) | — | |
| Durability | ≥500 cycles | |
| Parts Name | Material | Plating |
| Body | Brass | Tri-metal |
| Insulator | PTFE | — |
| Inner Conductor | Phosphor Bronze | Ag |
| Coupling Nut | Brass | Ni |
| Gasket | Silicone Rubber | — |
| Ferrule | Brass | Ni |
| Operating Temperature | _45 ℃-85 ℃ | |
| Weatherproof Rate | IP67 | |
| RoHs (2002/95/EC) | Compliant by exemption | |
