Home > Products > RF coaxial connectors > 4.3/10 Male to N Female Connector Adaptor
4.3/10 Male to N Female Connector Adaptor
US$ 3.1 - 6.51
/ Piece
100 Pieces(Min. Order)
- Shanghai Ning Bo Beijing Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Four Star | |
| Model Number | 4.3/10/N-JK | Type | Adapter | |
| Application | RF | Gender | Other, Male to Female |
Product Description
Product Description
4.3/10 Male to N Female Connector Adaptor
| 4.3/10 Male to N Female Connector Adaptor | ||
| Model No. | 4.3/10/N-JK | |
| Interface | 4.3/10/IEC 60169-16; | |
| Electrical | ||
| Characteristic Impedance | 50ohm | |
| Typical Frequency Range | DC-11GHz | |
| VSWR | ≤1.10@DC-3000MHz | |
| 3rd Order IM (PIM3) | ≤ -157dBc@2×20W | |
| Dielectric Withstanding Voltage | ≥4000V RMS,50Hz,at sea level | |
| Dielectric Resistance | ≥10000MΩ | |
| Contact Resistance | Center Contact ≤0.4mΩ | Outer Contact ≤1 .5mΩ |
| Mechanical | ||
| Durability | Mating cycles ≥500 | |
| Material and Plating | ||
| Parts Name | Material | Plating |
| Body | Brass | Tri-Metal(CuZnSn) |
| Insulator | PTFE | — |
| Inner Conductor | Phosphor Bronze | Ag |
| Coupling Nut | Brass | Tri-Metal(CuZnSn) |
| Gasket | Silicone Rubber | — |
| Cable Clamp | Brass | — |
| Ferrule | — | — |
| Environmental | ||
| Operating Temperature | -45 ℃-85 ℃ | |
| Weatherproof Rate | IP67 | |
| RoHs (2002/95/EC) | Compliant by exemption | |
| Suitable Cable Family | — | |
