AC V/I Digital Panel Meter
- 2000 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | YADA | |
| Model Number | YD9000 series | Measuring Current Range | 1A,5A | |
| Measuring Voltage Range | 100V,220V,380V | Accuracy Class | 0.5 | |
| Operating Temperature | -25℃~55℃ |
Product Description
Specifications
AC V/I Digital Panel Meter1.Programmable
2.DC4-20mA output,capacity output.
3.High accuracy.
4.Modbus -RTU protocol
AC V/Digital Panel Meter:
YD9000 Series AC Voltage/Current panel meter measures and displays the voltage/current of the three phase system with added functions of RS485 communication output, analog output, and contact output. It is programmable for the analog output and the contact output (Models in dimension 48mm×48mm have display function only).The digital panel meter displays real time value of voltage/current. Parameters such as address, baud rate, transformation ratio, analog output, relay output and return difference can be set manually on keyboard or by PC through RS485 communication (These parameters can not be set by the models in dimension 48mm×48mm, but can be made in the factory according to the customers requirements).With its reliable performance, YD9000 series panel meter is an economical and practical AC voltage/current measurement device.
Function Code
Models in 48 mm×48 mm×100mm has the functions of measuring and displaying only.
Performance |
Standard compliance | GB/T13850-1998 IEC688:1992 |
| |
| DL/T721-2000 IEC61000-4 |
| |
Max. Display | 9999 |
| |
Resolution | V: 0.1V I: 0.001A |
| |
Input Range | V: AC 0600V I: AC 06A |
| |
Accuracy | Class 0.5 |
| |
Absorbed Power | Voltage loop: <0.6VA, Current loop: <0.1VA |
| |
Overload resistance | Voltage: 2 times of normal value input, continuous |
| |
| Current: 2 times of normal value input, continuous /10 times, 10s |
| |
Measuring speed | About 2.5 times/s |
| |
Frequency | 40200Hz |
| |
Load capacity | <400Ω420mA output |
| |
Communication protocol | Modbus-RTU |
| |
Contact capacity | 220V/380V·5A |
| |
Aux. power supply | AC220V±20,50/60Hz,≤3VA |
| |
| Or DC100V300V(customized) |
| |
Working frequency withstand voltage | Between power supply/input/output: ≥AC2kV/min·1mA |
| |
Insulation resistance | ≥100MΩ | ||
Immunity to electrical fast transient/burstEFT: | 2KV 5KHz |
| |
Immunity to Surge voltage | 2KV 1.2/50us |
| |
