Single phase electronics energy meter
- 5000 Piece / Pieces per Month
- Shenzhen
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | YADA | |
| Model Number | DDS3366M-24 | Display Type | Other | |
| Phase | Single Phase | Accuracy Class | 1.0 | |
| Operating Temperature | -25℃~55℃ | Dimensions | 200mm X 100mm X 38mm |
Product Description
Specifications
1.Reverse power consumption is calculated into forward consumption2.LCD display,6 integers,1 decimals
3.Freeze the energy
DDS3366M-24 single-phase multi-loops energy meter is a 24 loops single-phase load energy computing meter, which is developed for intelligent power distribution, industrial automation and building intelligent security monitoring.
Features
Ø Sliding way installation
Ø It can be monitoring voltage, current, power and energy of 24-loops electricity consumptions.
With 12 months energy historic records
Model | DDS3366M-24 |
Accuracy(active) | 1.0 |
Rated voltage | 220V |
Rated current | 10(40)A,20(80)A |
Start-up curren | 0.004Ib |
Working voltage | 0.8Un~1.1Un(max.:0.7Un~1.2Un) |
Voltage circuit consumption | ≤10VA,5W |
Communicaiton port | RS485 |
Electrical Characteristics | |
Measuring Characteristics | 24 single-phase loops |
Computation |
Active energy |
Energy clearing |
With 12 months energy historic records |
Communication | |
Communication protocol |
ModbusRTU and DL/T645-1997 |
Communication port |
RS485 |
Data Format | E-8-1 |
Baud rate |
1200~19200 |
Mechanical properties | |
Dimensions |
L x W x T 200×100×38mm |
Installation |
35mm Standard DIN sliding-way |
