Double Shear Beam Bridge type load cell

FOB Price

US$ 200 - 1,500 / Piece

10 Pieces(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Bridge type load cell/Weighing Sensor

Bridge type load cell Dimensions(mm)

Bridge type load cell Specifications

Emax(Max. capacity)	t	50~200
Sensitivity	mV/V	1.0±0.002
Accuracy class		D1
Maximum number of verification intervals	nmax	1000
Minimum load cell verification interval	Vmin	Emax/3000
Combined error	%F.S	≤±0.05
Creep	%F.S/30min	≤±0.05
Temperature effect on sensitivity	%F.S/10°C	≤±0.05
Temperature effect on zero	%F.S/10°C	≤±0.04
Zero balance	%F.S	±1.0
Input resistance	Ω	730±10Ω
Output resistance	Ω	703±5Ω
Service temperature range	°C	-30...+70
Safe overload	%F.S	150
Ultimate overload	%F.S	300
Recommended excitation voltage	V	5…15
Insulation resistance	MΩ/50V	>5000
Protection class		IP67
Load cell material		Alloy steel
Cable length	m	12m
Cable outer caliber	mm	Φ5

Bridge type load cell Features

Planar load bearing bridge , reasonable structure

Simple and reliable load bearing ,easy to use ,simple to install scale ,traveling crane scale and other weighing systems in steel industry.

Widely used in consecutive-casting bale scale , middle bag scale ,steel ladle

Bridge type load cell Application

truck scales,rail scales,bin and hopper scales,etc.
