High Precision Chc X91 Gps Gnss Rtk System
US$ 10,000 - 11,100
/ Piece
1 Piece(Min. Order)
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Shanghai, China | Brand Name | CHC | |
| Model Number | X91+ |
Product Description
| GNSS Characteristics | |
| 220 channels | GPS: L1C/A,L1C,L2C, L2E, L5 |
| GLONASS: L1C/A, L1P, L2C/A, L2P, L3 | |
| SBAS: WAAS, EGNOS, MSAS | |
| Galileo: E1, E5A, E5B (test) | |
| Beidou: B1, B2(optional) |
| Advanced multipath mitigation |
| Low noise carrier phase measurement |
| Performance Specifications (1) | |
| Real Time Kinematics (RTK) | Horizontal: 8mm+1ppm |
| Vertical: 15mm+1ppm RMS | |
| Initialization time: typically<10s | |
| Initialization reliability: typically >99.9% | |
| Post Processing Static | Horizontal: 3mm+0.5ppm RMS |
| Vertical: 5mm+0.5ppm RMS | |
| Baseline Length: ≤300km | |
| With SBAS | <1 m RMS |
| Communications | |
| 1 RS232 serial port | |
| 1 high-speed USB | |
| Integrated GSM/GPRS modem | |
| Integrated Bluetooth ® class 2 | |
| CHC Radio modem internal Rx | 430-450 / 450-470 Mhz |
| Optional radio modem (2) | Internal Rx/Tx:403-473 Mhz |
| External Tx DL5: 1W-20W adjustable | |
| Protocols | RTCM2.1, RTCM2.3, RTCM3.0, CMR, CMR+ input and output |
| NMEA0183 outputs |
| RINEX and HCN outputs for GNSS raw data | |
| Data Storage | 4 GB internal memory |
| GPS device mounts as a USB external hard drive |
| Physical | |
| Size (H×D) | 85 ×180 mm (3.3 ×7.1 in) |
| Weight | 1.35Kg with battery (48 oz) |
| Working Temperature | -40 °C − +65°C (-40 °F − 149°F) |
| Storage Temperature | -40 °C − +75°C (-40 °F − 167°F) |
| Humidity | 100% condensation |
| Dustproof | IP67 |
| Waterproof | Protected from temporary immersion to depth of 1 meter floats. |
| Shock | Survives a 2−meter drop on to concrete |
| Electrical | |
| Typical power consumption | 2.6 W |
| Battery capacity | 2200 mAh |
| Operating times on internal battery | Up to 6 hours typical |
| External power input | 9-18 VDC |
| Software (optional) | |
| CHC's Landstar field data collection software | |
| Carlson's SurvCE field data collection software | |
(1) Accuracy and reliability specifications may be affected by multipath, satellite geometry and atmospheric conditions. Performances assume minimum of 5 satellites and follow up of recommended genernal GPS practices.
(2) UHF type approvals are country specific.
